XES Synergix 8825/8830 Printer Operator Manual 16
MEDIA INFORMATION
Media View Menu (cont.)
MEDIA IN IS 36.0 INCH BOND
[ENTER] TO CHANGE
SELECT MEDIA WIDTH <36.0 INCH>
<11.0 INCH>
<12.0 INCH>
<17.0 INCH>
<18.0 INCH>
<22.0 INCH>
<24.0 INCH>
<30.0 INCH>
<34.0 INCH>
<36.0 INCH>
2. Press the Next or the Previous button in order to scroll through the current
media selections:
• Roll 1
•
Roll 2 (Optional on the 8825)
•
Roll 3 (Not available on the 8825)
•
Bypass Shelf (Optional on the 8825)
NOTE: Media size selection does not apply to the Bypass Shelf.
3. Press the Enter button in order to select a media source.
4. Press the Next or the Previous button in order to scroll through the media
sizes.
•
Press the Enter button in order to select a media size:
5. Press the Exit button in order to go back to the media source selection.
<297 mm.>
<353 mm.>
<420 mm.>
<500 mm.>
<594 mm.>
<620 mm.>
<707 mm.>
<750 mm.>
<841 mm.>
<860 mm.>
<880 mm.>
<900 mm.>
