XES Synergix 8825/8830 Printer Operator Manual 11
MEDIA INFORMATION
Loading the Rolls of Media
Note: Load media in the drawers
before switching on the power or
after the printer is ready to print.
1. Raise the output tray (A) if
necessary and then lift the
handle in order to pull out the
Media Roll Drawer 1, 2 (Optional
on 8825), or 3 (Not available 0n
8825).
4. Lift out the used roll of media. 2. Squeeze the two knobs (A)
together in order to release the
latch.
3. Rotate the roll to rewind the
remaining media onto the roll.
5. Stand the roll assembly on end.
6. Squeeze the lever at the end of
the Media Roll Support Tube
and remove the tube from the
used roll of media.
A
3
2
1
A
