B2500
1 - Installation
B2500 MFP User’s Guide
9
Terminal description
Front side
1 Commands panel
2 Scanner Cover
3 Paper output
4 Master USB connection (USB key)
5 Cartridge access cover
6 Paper tray
7 Manual paper feed setup guides
8 Manual Input Tray
9 Fold-down stop for paper delivery
10 Smart card insertion point
1
2
3
4
5
6
7
9
10
8
