ZyXEL AG-120 User’s Guide
Chapter 5 Access Point Mode Configuration 67
5.3 The Configuration Screen
Click Configuration in the ZyXEL utility screen to display the screen as shown.
Figure 41 Access Point Mode: Configuration
Transmission Rate This field displays the current transmission rate of the AG-120 in megabits per
second (Mbps).
Security This field shows whether data encryption is activated (WEP) or inactive (Disabled).
MAC This field displays the MAC address of the AG-120.
Output Power This field shows the strength of the AG-120’s antenna gain or transmission power.
Association List This table lists up to 16 wireless clients that are currently connected to the AG-120.
or denotes a wireless client without WEP security.
denotes a wireless client with WEP security enabled.
MAC Address This field displays the MAC addresses of a wireless client that is currently
connected to the AG-120.
Refresh Click Refresh to update this screen.
Table 16 Access Point Mode: Link Info (continued)
LABEL DESCRIPTION
