ZyXEL AG-120 User’s Guide
66 Chapter 5 Access Point Mode Configuration
5.1.2 Additional Setup Requirements
To bridge your wired and wireless network using the AG-120, the following requirements
must be met:
1 The AG-120 must be installed on a computer connected to the wired network.
2 Either configure network sharing (refer to Appendix B on page 66 for an example) or
bridge the two interfaces (wireless and wired) on the computer.
3 Set the wireless station’s IP address to be dynamic if you want the wireless stations to
access the wired network or the Internet through the AG-120. Refer to Appendix E on
page 97 for how to configure your computer’s IP address.
5.2 The Link Info Screen
Select the AP Mode check box and wait for about five seconds to display the screen as shown.
Figure 40 Access Point Mode: Link Info
The following table describes the labels in this screen.
Table 16 Access Point Mode: Link Info
LABEL DESCRIPTION
Status
SSID This field displays the name that identifies your AG-120 in the wireless LAN
network.
Current Channel This field displays the radio channel the AG-120 is currently using.
