ZyXEL AG-120 User’s Guide
Chapter 4 Wireless Station Mode Configuration 55
The following table describes the labels in this screen.
4.4 The Profile Screen
A profile is a set of wireless parameters that you need to connect to a wireless network. With a
profile activated, each time you start the AG-120, it automatically scans for the specific SSID
and joins that network with the pre-defined wireless security settings. If the specified network
is not available, the AG-120 cannot connect to a network.
Click the Profile tab in the ZyXEL utility program to display the Profile screen as shown next.
The profile function allows you to save the wireless network settings in this screen, or use one
of the pre-configured network profiles.
Table 10 Station Mode: Confirm New Settings
LABEL DESCRIPTION
Network(SSID) This field displays the SSID previously entered.
Network Type This field displays the network type (Infrastructure or Ad-Hoc) of the wireless
device.
Security This field shows whether data encryption is active (WEP, WPA-PSK, WPA, 802.1x,
WPA2, WPA2-PSK) or inactive (Disabled).
Channel This field displays the channel number used by the profile.
Back Click Back to return to the previous screen.
Save Click Save to save the changes back to the AG-120 and display the Link Info
screen.
Exit Click Exit to discard changes and return to the Site Survey screen.
