Setting up workstations
2-20 Guide to Submitting Jobs from the Client
• Telnet session
• Another method that complies with the Port 9100 / socket
printing TCP standards.
Setting up a new
printer
on Windows 2000
To set up a new printer on Windows 2000:
1. Obtain a driver for the printer to be used.
2. Access the Add Printer Wizard by selecting Add Printer from
the Control Panel / Settings / Printer folder.
3. Select Local Printer and disable Automatically detect and
install my plug and play printer. Click Next.
4.Select Create a raw port. The Type will automatically be
set to Standard TCP/IP Port. This is port 9100. Click Next.
5.The Add Standard TCP/IP Port Wizard window displays.
Click Next.
6.Enter the Printer Name (the name used for NSF lookups) or
the IP address. Windows will automatically create a port
name. The port may be renamed to one that best fits the
printer name and the assigned virtual printer.
NOTE: You may want to add the port number or the virtual
printer name to the end of the address, to help separate other
ports on the same NPS/IPS system.
Click Next.
7. The Additional Port Information Required window displays.
Select Custom and click Settings. Click OK.
8. The Configure Standard TCP/IP Port Monitor window
displays, listing the Port Name and the Printer Name/IP
Address you set up. Select Raw and choose the Port
Number to match the NPS/IPS setup for the virtual printer
selected.
NOTE: If more than one port is setup on the NPS/IPS
system, a separate printer may be set up in windows 2000 for
each.
Click OK.
9. The Add Printer Wizard screen displays. Select the
appropriate driver for the NPS/IPS system.
10. Follow and complete the rest of the Wizard screens as
appropriate. The system will display a summary of your
selections. If they are correct, click Finish.
