M10 x 45mm Bolt (51)

M10 x 65mm Bolt (80)

M10 x 50mm Bolt (81)

M10 x 68mm Bolt (84)

M10 x 65mm Carriage Bolt (88)

M8 x 15mm Bolt (97)

M6 x 16mm Bolt (89)

M6 x 35mm Bolt (83)

M4 x 25mm Self-
tapping Screw (103)

M10 Nylon Locknut (101)

M8 Nylon Locknut (87)

M6 Nylon Locknut (102)

M12 Nut (58)

50mm Washer (95)

M8 Washer (100)

M4 Washer (104)

M4 x 15mm Self-

tapping Screw (107)

M10 Washer (99)

PART IDENTIFICATION CHART

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
