SQUEEGEE LIFT-DISK
86317500 CHARIOT SCRUBBER 11/15/08
5-46
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86068190
140793
1
BRACKET, ACTUATOR MOUNT
2
86273820
70019
1
SCR, 1/4-20 X 1.25 HHCS
3
86000870
05254
1
ACTUATOR, 36VDC, 4.5” STROKE
4
86083490
66831
1
PLATE, PULLEY MOUNT, CORNER
5
86068230
140840
1
BRACKET, SQG LIFT PULLEY MOUNT
6
86270870
57029
3
NUT, 1/4-28 HEX SS
7
86002780
270098
1
CABLE, SQUEEGEE LIFT DELUXE
8
86277410
70840
4
SCR, 5/16-18 X 5/8 CARRIAGE SS
9
86075430
270700
1
COVER, SQUEEGEE LIFT
10
86270830
57023
9
NUT, 5/16-18 HEX NYLOCK SS
11
86276070
70593
3
SCR, 5/16-18 X 3/4 CARRIAGE SS
12
86277400
70839
2
SCR, 5/16-8 X 1.75 BSHCS SS
13
86010670
87029
10
WASHER, 5/16 FLAT SS
14
86277460
70847
1
SCR, 5/16-18 X 5/8 BSHCS SS
15
86271870
57290
2
NUT, 1/4-20 HEX NYLOCK THIN SS
16
86223370
66464
6
PULLEY, PLASTIC 3.0 DIA
17
86231150
09151
5
BUSHING, FLANGE, .314ID X .502OD
18
86083440
66824
1
PLATE, PULLEY MOUNTING, CENTER
19
86276760
70724
2
SCR, 5/16-18 X 1.25 BSHCS SS
20
86274720
70264
2
SCR, 5/16-18 X 1.50 HHCS SS
21
86071300
140843
1
BRACKET, PULLEY RETAINER, DOUBLE
22
86224290
730008
2
SPACER, .317ID X .5OD X .44 LG
23
86071310
140844
1
BRKT, PULLEY RETAINER, DOUBLE
24
86083500
66832
1
PLATE, PULLEY RETAINER, CORNER
25
86271840
57285
1
NUT, 5/16-18 HEX NYLOCK THIN SS
26
86228880
09132
1
BEARING, .314 ID X .503 OD X 1
27
86277480
70850
2
SCR, 5/16-18 X 1/2 PTHMS SS
