SQUEEGEE LIFT-CYLINDRICAL
86317500 CHARIOT SCRUBBER 11/15/08 5-48
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86316550 - 1 ACTUATOR, 36VDC, 4.5" STROKE
2 86315270 - 1 BRKT ASSY, ACTUATOR MOUNT
3 86315250 - 1 YOKE, CABLE
4 86315000 - 1 SQUEEGEE MOUNT ASSY
5 86314820 - 1 CABLE ASSY, SQUEEGEE
6 86273740 70010 1 SCR, 1/4-20 X 1.5 HHCS SS
7 86224370 730335 4 SPACER, 1 OD X .391 ID X .500
8 86224290 730008 1 SPACER, .317ID X .5OD X .44LG
9 86259420 87232 8 WASHER, THRUST.51 ID X 1 ODBRO
10 86010670 87029 8 WASHER, 5/16 X 3/4 SS
11 86008650 80604 1 COTTER, 1/4 RING
12 86277480 70850 1 SCR, 5/16-18X1/2 PTHMS SS
13 86276760 70724 3 SCR, 5/16-18 X 1.25 BSHCS SS
14 86276690 70715 4 SCR, 5/16-18 X 1.75 CARR SS
15 86007020 70673 1 SCR, 5/16-18 X 1.25 HHCS SS
16 86274720 70264 1 SCR, 5/16-18 X 1.50 HHCS SS
17 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS SS
18 86073600 66833 1 BRKT, PULLEY RETAINER, SINGLE
19 86083500 66832 1 PLATE, PULLEY RETAINER, CORNER
20 86083490 66831 1 PLATE, PULLEY MOUNT, CORNER
21 86083440 66824 1 PLATE, PULLEY MOUNTING, CENTER
22 86223370 66464 4 PULLEY,PLASTIC 3.0 DIA
23 86272470 66270 1 PIN, CLEVIS 3/16 X .75 PLTD
24 86271870 57290 1 NUT, 1/4-20 HEX NYLOCK THIN SS
25 86005810 57245 1 NUT, 1/4-20 HEX NYLOCK SS
26 86270990 57090 1 NUT, 10-32 HEX NYLOCK SS
27 86270830 57023 9 NUT, 5/16-18 HEX NYLOCK SS
28 86270770 57006 1 NUT, 1/4-20 HEX
29 86231150 09151 4 BEARING FLANGED .314IDX.502OD
30 86228840 09124 4 BEARING, FLANGED .313IDX.502OD
