SCRUB DECK-CYLINDRICAL
86217500 CHARIOT SCRUBBER 11/15/08
5-26
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
FROM
NOTES:
1
50448660
-
2
RETAINER PLATE TRANSMISSION
2
73060310
-
10
SCREW M 6X16-A2-70 DIN 7984
3
73120260
-
10
WASHER 6-A2 ISO 7090
4
73130030
-
10
SPRING WASHER B 6FST-A3E DIN 127
5 50448580 -
2 HOLDER-UP
6 50560100 -
2 ROCKER
BR-VS
7
51005530
-
2
DRIVESHAFT BR 65/90
8
73180020
-
2
PARALLEL KEY 5X5X16-C45R DIN 6885-1
9
73430150
-
2
LOCKING RING 15X1-FST-RF DIN 471
10 51163400 -
2 BOLT
HOLDER-UP
11 73056370 -
2
COUNTERSUNK SCREW M8X16-A2-70
ISO 10642
12
51163540
-
2
BRUSH TRANSMISSION BR
13
56254830
-
2
BELT PULLEY 57MM
14 63431490 -
2 QUICK-FASTENER
15 63484420 -
2 RIBBED
V-BELT
16
63631580
-
2
JOINT RING NILOSRING
17 50332060 -
4 LOCKING
PART
18 74011150 -
4
BALL BEARING 6002-2RS-WAELZLAGST
DIN 62
19
73432310
-
2
LOCKING RING 32X1,2-ST-PH DIN 472
20
73030470
-
5
SCREW M6X16-ST-R3R (IN6RD)
21 50333940 -
2 LOCKING
PART
22 50332410 -
1 COVERING
CAP
LEFT
23 73030370 -
28 SCREW
M5X10-ST-P2R
(IN6RD)
24 50332420 -
1 COVERING
CAP
RIGHT
25 50334030 -
1 COVER
PLATE
26 55150960 -
2 ROLLER
27 53830970 -
1 DECAL
28
50615800
-
1
BRUSH HOUSING BR 65
29
50707530
-
1
TANK REFUSE 65
30
51902610
-
1
STRIP WATER DISTRIBUTOR
31
46239200
-
2
MOTOR COMPLETE 24V/600W
32 66102160 -
1 CARBON
BRUSHES
33 66130250 -
2 BLOWER
WHEEL
34 53948230 -
2 SPLASH
GUARD
35
50448670
-
2
RETAINER STRIP SPLASH GUARD
36
50094010
-
1
BRACKET RIGHT SCRAPER LIP
37
5009420
-
1
BRACKET LEFT SCRAPER LIP
38 51163390 -
2 THREADED
BOLT
39 50332400 -
2 HAND
WHEEL
40 63304070 -
2 SPRING
CLIP
41 63908920 -
1 SPIRAL
HOSE
42 66463290 -
2 RED
PLUG
43 66463300 -
2 BLUE
PLUG
44
73031070
-
3
SCREW 5X16-10.9-P2R (K-IN6RD)
45 66469790 -
4 SWITCH
CONTACT
46 63884820 -
1 HOSE
COUPLING
47
63211960
-
1
STAR GRIP M5X10
-
27630040
-
-
BRUSH HEAD R 65 CM W/SIDE
DECK,COMPLETE
