SCRUB DECK SKIRTS-DISK
86317500 CHARIOT SCRUBBER 11/15/08 5-34
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
2 86070960 140773 2 BRKT, SKIRT STOP, SCRUBDECK
3 86276070 70593 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
4 86228900 09138 2 BEARING FLANGED, .252IDX.503OD
5 86005810 57245 6 NUT, 1/4-20 HEX NYLOCK SS
6 86276330 70634 2 SCR, 1/4-20 X 1.25 CARRIAGE BZ
7 86276950 70772 8 SCR, 1/4-20 X 3/4 CARRIAGE SS
8 86277410 70840 6 SCR, 5/16-18 X 5/8 CARRIAGE SS
9 86271950 57300 6 NUT, 5/16-18 X 1 COUPLING SS
10 86079130 620068 4 PLATE, SKIRT, SPACER
11 86007650 730329 4 SPACER, .438D X .317ID X .25L
12 86007070 70849 6 SCR, 5/16-18 X 1.00 PTMS SS
13 86066460 140769 1 BAND, SKIRT, LEFT
14 86001560 140754 1 BLADE, SKIRT, SCRBDCK, 24IN LFT
15 86091770 140765 1 BRKT, SKIRT SCRUBDECK, LEFT
16 86001700 140780 1 BLADE, SKIRT, SCRUBDECK, FRONT
17 86066480 140781 1 BAND, SKIRT, SCRUBECK, FRONT
18 86091780 140766 1 BRKT, SKIRT, SCRUBDECK, RIGHT
19 86001570 140755 1 BLADE, SKIRT, SCRBDCK, 24IN RGT
20 86066470 140770 1 BAND, SKIRT, RIGHT
21 86277500 70853 3 SCR, 1/4-20 X 5/8 CARR SS
22 86271870 57290 3 NUT, 1/4-20 HEX NYLOCK THIN SS
23 86026470 47459 - KIT, SKIRT LEFT SERVICE ONLY
24 86026460 47458 - KIT, SKIRT RIGHT SERVICE ONLY
