PEDAL PLATFORM
86317500 CHARIOT SCRUBBER 11/15/08
5-16
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86008680
80607
1
COTTER, 1/2” RING
2
86274690
70258
2
SCR, 5/16-18 X 1.5 HHCS GR5PLT
3
86264920
27049
3
CABLE TIE, 7” UL/CSA
4
86231070
730328
2
BUMPER, 1 X 1.375 RUBBER
5
86010670
87029
5
WASHER, 5/16 FLAT SS
6
86259430
87485
4
M12 FLAT WASHER
7
86010770
87143
2
WASHER, 7/16ID X1D.08 FLT SS
8
86270830
57023
4
NUT, 5/16-18 HEX NYLOCK SS
9
86256470
70852
2
STUB AXLE, M12-1.75 X 45MM
10
86278850
80613
2
WASHER, .506 ID X .94D X .064 NYL
11
86248920
66487
1
PIN, CLEVIS 1/2 X 2.25
12
86064480
629993
1
PLATE, SWITCH BASE
13
86271190
57142
2
NUT, M12 X 1.75 HEX DIN934 PLT
14
86007780
73576
1
SPRING, COMP .60D X2.0L X .045W
15
86259440
87486
2
WASHER, M12 SPRING LOCK
