Windsor Chariot Scrubber 10061160 - Manual (Page 73)

SCRUB BRUSH/PAD DRIVER-DISK
86317500 CHARIOT SCRUBBER 11/15/08 5-20
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86000170 02400 2 PAD DRIVER, 12” SD
2A 86000180 02401 2 BRUSH, 12” POLYPROPYLENE SD
2B 86000190 02402 2 BRUSH, 12” NYLON SD
2C 86000200 02404 2 BRUSH, 12” MILD GRIT SD
2D 86283820 02405 2 BRUSH, 12” SUPER AGG SD
3 86005070 51284 1 LOCK, PAD CENTER SNAP, TWO STEP
4 86276590 70695 3 SCR, #12 X 1 PPHSMS SS
5 86276580 70694 1 SCR, 8-32 X 3/4 PTHMS
6 86276600 70696 3 SCR, #10 X 3/4 PTHSMS SS
7 86007910 73817 1 SPRING, EXT .31 D X 2.0 L X .03 W SS
8 86007280 730011 1 SOCKET, DRIVE BRUSH
9 86005940 62852 1 PLATE, BRUSH RELEASE
