Windsor Chariot Scrubber 10061160 - Manual (Page 103)

SQUEEGEE SWING
86317500 CHARIOT SCRUBBER 11/15/08 5-50
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86276690 70715 7 SCR, 5/16-18 X 1.75 CARR SS
2 86091530 140787 1 BRACKET, SQUEEGEE SIDE PIVOT
3 86090300 87247 2 WASHER, 1.25 ID X .075 OCTAGON
4 86083370 66475 2 PLATE, SQG SWING SPACER
5 86091540 140800 1 BRACKET, H PIVOT MOUNT
6 86270830 57023 13 NUT, 5/16-18 HEX NYLOCK SS
7 86271530 57216 2 NUT, 3/8-24 HEX NYLOCK
8 86008810 80697 1 BALL JOINT ASY, 3/8-24 RH
9 86271980 57303 1 NUT, 3/8-24 WING SS
10 86223590 67510 1 ROD, CAMBER ADJUST
11 86001320 140353 1 BALL JOINT ASSY, 3/8-24 LH
12 86091810 140798 1 BRKT, SQG QUICK CONNECT
13 86224290 730008 2 SPACER, .317ID X .500 X .44LG
14 86083400 66479 1 PLATE, CABLE RETAINING
15 86276760 70724 2 SCR, 5/16-18 X 1.25 BSHCS SS
16 86272630 80771 1 PIN, CLEVIS 1/4 X .88 PLTD
17 86008650 80604 1 COTTER, 1/4 RING
18 86228840 09124 4 BEARING, FLANGED .314 ID X .502 0D
19 86277030 70780 4 SCR, 5/16-18 X 1.25 CARRIAGE SS
20 86224380 730336 4 SPACER, 1 OD X .343 ID X 1.063
21 86083150 66446 2 PLATE, SQUEEGEE SWING
22 86083310 66468 1 PLATE, WHEEL RETAINER
23 86226030 89268 2 WHEEL, 1.000 OD X .323 ID X .750 SS
24 86222580 66466 2 PIN, .312 DIA X 1.250 LG SS
25 86070820 140740 1 BRKT, SQUEEGEE SWING HORIZ
