FRAME - LOWER
86317500 CHARIOT SCRUBBER 11/15/08 5-10
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86091420 05251 1 AXLE, REAR, WELDMENT
2 86270830 57023 24 NUT, 5/16-18 HEX NYLOCK SS
3 86197040 57264 4 NUT, 5/16-18 HEX ACORN
4 86271870 57290 4 NUT, 1/4-20 HEX NYLOCK THIN SS
5 86276070 70593 20 SCR, 5/16-18 X 3/4 CARRIAGE SS
6 86276950 70772 4 SCR, 1/4-20 X 3/4 CARRIAGE SS
7 86088750 75457 1 TRAY, SLIDE, RIGHT
8 86088760 75458 1 TRAY, SLIDE, LEFT
9 86010630 87013 4 WASHER, 1/4 X 5/8 FLAT SS
10 86010670 87029 6 WASHER, 5/16 X 3/4 SS
11 86279130 87083 4 WASHER, 5/16 SPLIT
12 86064300 140790 2 PAD, TIPPING BAR
13 86071120 140811 1 BRKT, BRACE, RIGHT REAR
14 86079290 620097 2 PLATE, REAR COVER ADJ.
15 86079320 620101 2 PLATE, PAD RETAINER
16A 86303720 - 1 BRKT, BRACE, LT. REAR SOL. DISK
16B 86071130 140812 1 BRKT BRACE, LT REAR CYLINDRICAL
17 86314900 - 1 FRAME, MAIN
18 86314960 - 1 BRKT, LINKAGE, LEFT
19 86314970 - 1 BRKT, LINKAGE, RIGHT
20 86314980 - 1 BRKT, BRACE, LEFT FRONT
21 86314990 - 1 BRKT, BRACE, RIGHT FRONT
22 86315210 - 1 BRKT, STRAINER
