SCRUB DECK ACTUATOR-CYLINDRICAL
86317500 CHARIOT SCRUBBER 11/15/08 5-32
REF PART NO.
PRV
NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86317340 - 3 SPACER, .498 X.313 X.500
2 86317330 - 3 PULLEY, 2 IN.
3 86316550 - 1 ACTUATOR, 36VDC, 4.5" STROKE
4 86315290 - 1 SPACER
5 86315260 - 1 BRKT ASSY, ACTUATOR
6 86315250 - 1 YOKE, CABLE
7 86315240 - 1 GUARD, PULLEY
8 86270770 57006 1 NUT, 1/4-20 HEX
9 86315150 - 1 PLATE, PULLEY, REAR
10 86315140 - 1 PLATE, PULLEY, FRONT
11 86315120 - 1 SPRING, EXTENSION
12 86315110 - 2 BRKT, DECK PIVOT
13 86315090 - 1 BELLCRANK ASSY, DECK
14 86314810 - 1 CABLE ASSY, DECK LIFT
15 86273740 70010 1 SCR, 1/4-20 X 1-5 HHCS SS
16 86224380 730336 2 SPACER, 1 OD X .391 ID X 1.063
17 86010780 87162 16 WASHER, 1/4 SPLIT
18 86010670 87029 6 WASHER, 5/16 X 3/4 SS
19 86231090 80809 2 BUMPER, RUBBER 5/16" ID X 1.50
20 86006980 70591 1 SCR, 10-32 X 1/2 HHCS SS
21 86136850 70241 3 SHOULDER BOLT, 5/16 OD X 5/8 L
22 86274460 70205 1 SCR, 1/4-20 X 3/8 HHCS
23 86273920 70049 2 SCR, 1/4-20 X 1.75 PPHMS SS
24 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS SS
25 86273780 70015 1 SCR, 1/4-20 X 3/4 HHCS SS
26 86273750 70011 12 SCR, 1/4-20 X 5/8 HHCS SS
27 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
28 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
