Windsor Chariot Scrubber 10061160 - Manual (Page 91)

SOLUTION-DISK
86317500 CHARIOT SCRUBBER 11/15/08 5-38
REF
PART
NO.
PRV
NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86248010 57312 1 NUT, 8/32 ACORN CAP, PLATED
2 86226950 40109 1 1” HOSE BARB X 3/4” GHT NYLON
3 86073960 22104 1 CAP, 3/4” GHT W/.17 HOLE
4 86235450 31068 1 ELBOW, 3/8 FPT PVC SCH 80
5 86233150 20042 5 CLAMP, 3/8 HOSE (D-SLOT)
6 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
7 86281940 39540 1 HOSE, 1/2ID WIRE BOUND X 40”
8 86198050 81923 1 TEE, 3/4 FPT
9 86240390 40075 1 HOSEBARB, 3/4 MPT X 1/2 90D
10 86282190 39616 1 HOSE, 1/2ID WIRE BOUND X 13”
11 86247760 80960 1 NIPPLE, 3/4 CLOSE PVCE
12 86240600 41526 1 HOSEBARB, 3/4 MPTX1, HOSE 90DEG
13 86197540 40013 1 HOSEBARB, 3/8 MPT X 1/2 DL
14 86225680 84201 1 VALVE, 3/8” FPT BALL
15 86197420 31026 1 ELBOW, 3/8 NPT STREET
16 86001590 40049 1 HOSEBARB, 3/8 MPT X 1/2 NYLON
17 86007940 73836 1 STRAINER, DEEP, 100 MESH
- 86005870 59021 - O-RING, FILTER SEAL RON-VIK
- 86136800 73839 - SCREEN, 100 MESH STRAINER DEEP
18 86281950 39541 1 HOSE, 1/2ID WIRE BOUND X 32”
19 86315510 - 1 HOSE, 1 X 40 DRAIN
20 86264920 27049 3 CABLE, TIE. 7” UL/CSA
21 86274410 70195 4 SCR, 10-32 X 1.25 PPHMS SS
22 86070690 140724 1 BRKT, SOLUTION PUMP
23 86010650 87018 4 WASHER, #10 X 9/16 OD
24 86006100 65176 1 PUMP ASM, 36V
25 86271820 57270 1 NUT, 5/16-18 CAPTIVE “J” PLTD
26 86279130 87083 1 WASHER, 5/16 SPLIT LOCK PLTD
27 86276780 70728 1 SCR, 5/16-18 X 3/4 HHCS SS
28 86197940 40027 2 HOSEBARB, 3/8MPTX1/2 90D DL
29 86246090 51461 1 LANYARD, .093 X 6”, LOOP - .26 EYE
30 86254320 730400 1 SPACER, .17 ID X .25 OD X 3/16 LG
31 86259450 87507 1 WASHER, 1.0 D X .1 THK, SEAL
32 86252730 70887 1 SCR, 8-32 X 1/2 BHCS SST
33 86233110 20018 1 CLAMP, 1.0” WORM GEAR
34 86233300 20101 1 CLAMP, 1.25” WORM GEAR SS
