WIRING-MAIN HARNESS
86317500 CHARIOT SCRUBBER 11/15/08
5-76
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL
NO.
FROM
NOTES:
1 86313710
-
1 HARNESS, MAIN
2 86318640
-
1 HARNESS, PUMP JUMPER
CYL ONLY
3 86318650
-
1 HARNESS, BRUSH MOTOR
CYL ONLY
4 86318660
-
1 HARNESS BRUSH ACTUATOR
CYL ONLY
5 86319780
-
1
HARNESS, WARNING LIGHTS
OPTION
OPTION
