WARNING LIGHTS - OPTION
86317500 CHARIOT SCRUBBER 11/15/08 6-8
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
2 86010650 87018 4 WASHER, #10 X 6/16 OD
3 86276820 70740 4 SCR, 10-32 X 1/2 PTHMS BLK
4 86071490 140871 1 BRKT, UPPER WARNING LIGHT
5 86270990 57090 2 NUT, 10-32 HEX NYLOCK SS
6 86246200 51454 2 LED AMBER LIGHT, 12V
7 86071500 140872 1 BRKT, LOWER WARNING LIGHT
