22 HP ProLiant DL360 Generation 4 Server Reference and Troubleshooting Guide
Server Status LED Status Battery Module Status
Server is on and is in the first 30
seconds after power up Green = On
Amber = On
Temporary lock-out state; data was lost due to
cable being detached
Server is off and is in data
retention mode Amber = Blinking every
15 seconds User data held in write cache is being backed up
Fan Module Locations
Item Description
1 Power supply zone fan module
2 Processor zone fan module
