W O L F C O O K T O P V E N T I L A T I O N
94
8'
TO
9'
(2.4 m – 2.7 m)
FLOOR TO
CEILING HEIGHT
24"
TO
30"*
(610 – 762)
TO
COUNTERTOP
21"
(533)
E
4"
(102)
6"
(152)
30"
OR
35
7
/
16
"
(762 or 900)
48
1
/
2
"
OR
50
7
/
8
"
(1232 or 1292)
MAXIMUM
HEIGHT OF HOOD
30
1
/
2
"
OR
32
11
/
16
"
(775 or 830)
MINIMUM
HEIGHT OF HOOD
*8' (2.4 m) ceilings will not allow for a 30" (762) maximum height above the countertop. Based on a 36" (914) high countertop, an 8' (2.4 m) ceiling
will allow for a maximum height above the countertop of 29
1
/
2
" (749) for Model CTWH30 and 27
5
/
16
" (694) for Model CTWH36.
LOCATION OF
ELECTRICAL
6
7
/
8
"
(175)
30
1
/
2
"
TO
48
1
/
2
"
(775 – 1232)
OVERALL HEIGHT
19
1
/
8
"
(486)
30"
(762)
OVERALL WIDTH
4
1
/
2
"
min
(114)
18"
(457)
12"
(305)
21"
(533)
OVERALL DEPTH
1
9
/
16
"
(40)
6"
(152)
O V E R A L L D I M E N S I O N S
Cooktop Wall Hoods
Model CTWH30
I N S T A L L A T I O N S P E C I F I C A T I O N S
Cooktop Wall Hoods
19
1
/
8
"
(486)
4
5
/
16
"
min
(110)
32
11
/
16
"
TO
50
7
/
8
"
(830 – 1292)
OVERALL HEIGHT
35
7
/
16
"
(900)
OVERALL WIDTH
18"
(457)
12"
(305)
21"
(533)
OVERALL DEPTH
9
1
/
4
"
(235)
1
9
/
16
"
(40)
8
11
/
16
"
(221)
S P E C I F I C A T I O N S
Model CTWH30
Overall Width
30" (762)
Overall Height
6
7
/
8
" (175)
(excluding chimney)
Overall Height
30
1
/
2
" (775)
(including chimney)
Maximum Height
48
1
/
2
" (1232)
(full extension)
Overall Depth
21" (533)
Bottom of Hood
to Countertop
24" (610) to 30" (762)
Duct Size
8" (203) Round
Discharge
Vertical
Internal Blower*
450 CFM
In-Line Blowers*
600 or 1100 CFM
Remote Blowers*
600, 900, 1200 or
1500 CFM
Electrical Supply
110/120 V AC, 60 Hz
15 amp circuit
Shipping Weight
85 lbs (39 kg)
(shell only)
*Blower options vary with the cooking
surface. Refer to the cooktop ventilation
recommendations on pages 115–116.
Model CTWH36
S P E C I F I C A T I O N S
Model CTWH36
Overall Width
35
7
/
16
" (900)
Overall Height
9
1
/
4
" (235)
(excluding chimney)
Overall Height
32
11
/
16
" (830)
(including chimney)
Maximum Height
50
7
/
8
" (1292)
(full extension)
Overall Depth
21" (533)
Bottom of Hood
to Countertop
24" (610) to 30" (762)
Duct Size
8" (203) Round
Discharge
Vertical
Internal Blowers*
600 or 900 CFM
In-Line Blowers*
600 or 1100 CFM
Remote Blowers*
600, 900, 1200 or
1500 CFM
Electrical Supply
110/120 V AC, 60 Hz
15 amp circuit
Shipping Weight
100 lbs (45 kg)
(shell only)
*Blower options vary with the cooking
surface. Refer to the cooktop ventilation
recommendations on pages 115–116.
Dimensions in
parentheses are in
millimeters unless
otherwise specified.
