Wolf Appliance Company SO30F/S User Manual
Page 80
Dimensions in
parentheses are in
millimeters unless
otherwise specified.
W O L F G A S R A N G E S
80
30"
min (762)
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
30"
(762) TO
36"
(914)
COUNTERTOP
TO BOTTOM OF
VENTILATION HOOD
VENTILATION
HOOD
30
1
/
4
"
(768)
FINISHED ROUGH
OPENING WIDTH
ISLAND INSTALLATIONS: 12" (305) MINIMUM CLEARANCE FROM BACK
OF RANGE TO COMBUSTIBLE REAR WALL ABOVE COUNTERTOP –
0" (0) TO NON-COMBUSTIBLE MATERIALS
G
5"
(127)
2"
(51)
12"
(305)
E
12"
(305)
10"
(254)
5
1
/
2
"
(140)
8"
(203)
LOCATION OF GAS SUPPLY EXTENDS
3" (76) ON FLOOR FROM BACK WALL
3"
(76)
36"
(914)
18"
min (457)
TO COUNTERTOP
37"
(940) TO
COOKING
SURFACE
13"
max
(330)
6"
min (152)
TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
30"
(762)
OVERALL WIDTH
36"
(914)
37"
(940)
OVERALL
HEIGHT TO
COOKING
SURFACE
2
1
/
2
"
(64)
24
1
/
2
"
(622)
25
1
/
4
"
(641)
LEGS AND CASTERS ALLOW
1" (25) HEIGHT ADJUSTMENT
43
3
/
8
"
(1102)
46
3
/
4
"
(1187)
WITH 10"
RISER
56
3
/
4
"
(1441)
WITH 20"
RISER
27
1
/
4
"
(692)
9
1
/
4
"
(235)
28
3
/
8
"
(721)
OVERALL DEPTH
41
3
/
4
"
(1060)
WITH 5"
RISER
I N S T A L L A T I O N S P E C I F I C A T I O N S
30" (762) Gas Range
O V E R A L L D I M E N S I O N S
30" (762) Gas Range
S P E C I F I C A T I O N S
30" (762) Gas Range
Overall Width
30" (762)
Overall Height
(to cooking surface) 37" (940)
Overall Depth
28
3
/
8
" (721)
Overall Oven
Interior Capacity
4.4 cu ft (125 L)
Overall Interior Dim
24" x 18
5
/
8
" x 17"
(W x H x D)
(610 x 473 x 432)
Usable Interior Dim
24" x 16
1
/
2
" x 17"
(W x H x D)
(610 x 419 x 432)
Opening Width
30
1
/
4
" (768)
Electrical Supply
110/120 V AC, 50/60 Hz
15 amp circuit
Power Cord
6' (1.8 m) 3-prong
Shipping Weight
325 lbs (147 kg)
M O D E L O P T I O N S
30" (762) Gas Range
Four Surface
Burners
R304
Natural gas model listed;
for LP gas add (-LP) to the
model number.
IMPORTANT NOTE: A
minimum 5" (127) riser is
required when installing a
30" (762) gas range against
a combustible surface.
Unit dimensions may vary to ±
1
/
8
" (3).
