Dimensions in
parentheses are in
millimeters unless
otherwise specified.
W O L F S E A L E D B U R N E R R A N G E T O P S
74
M O D E L O P T I O N S
30" (762) Sealed Burner
Rangetops
Four Surface
Burners
SRT304
Natural gas model listed;
for LP gas add (-LP) to the
model number.
VENTILATION
HOOD
30"
(762)
OPENING WIDTH
30"
min (762)
TO
36"
max (914)
TO BOTTOM OF
VENTILATION HOOD
30"
min (762)
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
3
/
4
"
(19)
PLATFORM
TOP VIEW
OF PLATFORM
E
G
16"
(406)
16"
(406)
4"
(102)
BACK
WALL
ISLAND INSTALLATIONS: 12" (305) MINIMUM
CLEARANCE FROM BACK OF RANGETOP TO
COMBUSTIBLE REAR WALL ABOVE COUNTERTOP–
0" (0) TO NON-COMBUSTIBLE MATERIALS
LOCATION OF GAS AND
ELECTRICAL SUPPLY CUT-OUT
WITHIN SHADED AREA
THROUGH BOTTOM OF
PLATFORM
36"
(914)
18"
min (457)
TO COUNTERTOP
3
/
4
"
(19)
PLATFORM
8
1
/
2
"
(216)
COOKING
SURFACE
7
1
/
2
"
(191)
24"
(610)
13"
max
(330)
6"
min (152)
TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
29
7
/
8
"
(759)
OVERALL WIDTH
24
1
/
4
"
(616)
12
1
/
2
"
(318)
WITH 5"
RISER
17
1
/
2
"
(445)
WITH 10"
RISER
27
1
/
2
"
(699)
WITH 20"
RISER
28
1
/
2
"
(724)
OVERALL DEPTH
8
1
/
2
"
(216)
OVERALL
HEIGHT
COOKING
SURFACE
7
1
/
2
"
(191)
9
1
/
4
"
(235)
I N S T A L L A T I O N S P E C I F I C A T I O N S
30" (762) Sealed Burner Rangetop
O V E R A L L D I M E N S I O N S
30" (762) Sealed Burner Rangetop
Unit dimensions may vary to ±
1
/
8
" (3).
S P E C I F I C A T I O N S
30" (762) Sealed Burner Rangetop
Overall Width
29
7
/
8
" (759)
Overall Height
(to cooking surface) 8
1
/
2
" (216)
Overall Depth
28
1
/
2
" (724)
Opening Width
30" (762)
Opening Height
7
1
/
2
" (191)
(platform to countertop)
Opening Depth
24" (1219)
Electrical Supply
110/120 V AC
50/60 Hz
15 amp circuit
Power Cord
6' (1.8 m) 3-prong
Shipping Weight
160 lbs (73 kg)
