W O L F E L E C T R I C C O O K T O P S
2"*
min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
19
1
/
4
"
(489)
COOKTOP CUT-OUT
DEPTH
2
1
/
2
"
min
(64)
36"
(914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13"
max
(330)
30"
(762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
24"
min
(610)
*Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18" (457) above countertop. **Minimum clearance from
rear edge of cooktop cut-out to combustible materials up to 18" (457) above countertop.
34
3
/
8
"
(873)
COOKTOP CUT-OUT WIDTH
34
3
/
8
"
(873)
COOKTOP CUT-OUT WIDTH
39"
(991)
RECOMMENDED CABINET WIDTH
36"
min (914)
4"
(102)
10"
(254)
3
1
/
2
"
(89)
36-INCH OVEN OPENING
3
3
/
4
"
min (95)
E
2
1
/
2
"
min
(64)
FRONT OF COUNTERTOP
19
1
/
4
"
(489)
COOKTOP
CUT-OUT DEPTH
2"**
(51)
21"
(533)
OVERALL
DEPTH
36"
(914)
OVERALL WIDTH
5"
(127)
3
3
/
4
"
(96)
CONDUIT
O V E R A L L D I M E N S I O N S
New Model CT36E
I N S T A L L A T I O N S P E C I F I C A T I O N S
36" (914) Framed Electric Cooktop
Countertop Cut-Out Dimensions
S P E C I F I C A T I O N S
New Model CT36E
Overall Width
36" (914)
Overall Height
3
3
/
4
" (96)
Overall Depth
21" (533)
Heating Elements
Four
Temperature Zones
Nine
Max Element Power
Triple
1050 / 2200 / 2700 W
Dual
700 / 2200 W
Singles
1200 W and (2) 1800 W
Singles with Bridge
4400 W
Cabinet Width
39" (991) rec
36" (914) min
Cabinet Depth
22
3
/
4
" (578) min
Height Clearance
4" (102) min
Cut-Out Width*
34
3
/
8
" (873)
Cut-Out Depth
19
1
/
4
" (489)
Electrical Supply
240 V AC / 60 Hz / 50 amp
208 V AC / 60 Hz / 40 amp
Conduit
4' (1.2 m) flexible 3-wire
Electrical Rating
10.5 kW at 240 V
7.9 kW at 208 V
Shipping Weight
60 lbs (27 kg)
*If the 36" (914) cooktop is to be used with
any combination of additional cooktop units or
modules with a filler strip, the cut-out width
increases to 35" (889).
The outer diameter of the heating elements are
12" (305), 9" (229), two 8" (203) and 6
1
/
2
" (165).
The bridge with elements is 8" (203) x 17" (432).
IMPORTANT NOTE: A minimum height clearance
of 5
3
/
4
" (146) is required between countertop and
any combustible surface directly below cooktop.
I N S T A L L A T I O N O P T I O N S
A Wolf 36" (914) L Series single oven may be
installed below the 36" (914) framed electric
cooktop. For this installation, unless you are
using cabinets deeper than 24" (610), it is
recommended that the electrical supply be
placed in the base cabinet to the right of the
oven. A Wolf 30" (762) L Series or E Series
single oven may also be installed below the
36" (914) framed electric cooktop. Refer to
the built-in ovens section for additional
specifications.
When a 36" (914) L Series oven is installed
below a cooktop, it is recommended that the
rough opening for the oven be 7
3
/
4
" (197) from
the floor to ease use of the oven door.
Unit dimensions may vary to ±
1
/
8
" (3).
M O D E L O P T I O N S
36" (914) Framed Electric Cooktop
Classic Trim Finish
CT36E/S
Platinum Trim Finish CT36E/P
Carbon Trim Finish
CT36E/B
Available November 2007
NEW
