4 ViewSonic PJL3211
Part names
Part names
Projector
(1) Lamp cover (48)
The lamp unt s nsde.
(2) Focus rng (16)
(3) Zoom rng (16)
(4) Control panel (5)
(5) Speaker (32)
(6) Elevator knobs (x 2) (16)
(7) Elevator feet (x 2) (16)
(8) Lens (13, 51)
(9) Lens cover (3)
(10) Intake vents
(11) Flter cover (50)
The air filter and intake vent are inside.
(12) Exhaust vents
(13) AC nlet (10)
(14) VIDEO port (8)
(15) S-VIDEO port (8)
(16) Securty slot (10)
(17) COMPUTER IN1 port (8)
(18) Shutdown swtch (54)
(19) COMPUTER IN2 port (8)
(20) USB port (8)
(21) AUDIO IN1 port (8)
(22) AUDIO IN2 port (8)
(23) AUDIO OUT port (8)
(24) CONTROL port (8)
(25) MONITOR OUT port (8)
WARNING ►HOT! : Do not touch around the lamp cover and the exhaust
vents durng use or just after use, snce t s too hot.
►Do not look into the lens or vents while the lamp is on, since the strong light
s not good for your eyes.
►Do not handle the elevator knobs without holding the projector, since the
projector may drop down.
CAUTION ►Mantan normal ventlaton to prevent the projector from heatng
up. Do not cover, block or plug up the vents. Do not place anythng that can stck or
be sucked to the vents, around the intake vents. Clean the air filter periodically.
►Do not use the security slot to prevent the projector from falling down, since it
s not desgned for t.
►Use the shutdown switch only when the projector is not turned off by normal
procedure, snce pushng ths swtch stops operaton of the projector wthout
coolng t down.
HOT!
K
COMPUTER IN1 COMPUTER IN2
USB
AUDIO IN1
AUDIO IN2
S-VIDEO
VIDEO
MONITOR OUT CONTROL
AUDIO OUT
HOT! (1) (2) (3) (4)
(7)
(10)
(9) (8) (11)
(6)
(7)
(5)
(12)
(13)
(15) (16) (17) (18) (19) (20)
(25)
(21) (22) (14)
(Bottom)
(24) (23)
