26 ViewSonic PJL3211
IMAGE Menu
IMAGE Menu
Item Description
ASPECT
Using the ▲/▼ buttons switches the mode for aspect ratio.
For a PC signal
NORMAL у 4:3 у 16:9 у SMALL
For a Video signal, s-video signal or component video signal
4:3 у 16:9 у 14:9 у SMALL
For no signal
4:3 (fixed)
• Ths tem can be selected only for a proper sgnal.
• The NORMAL mode keeps the orgnal aspect rato settng.
• Performng the automatc adjustment ntalzes the aspect rato settng.
OVER SCAN
Using the ▲/▼ buttons adjusts the over-scan ratio.
Large (It reduces pcture) ó Small (It magnifies picture)
• Ths tem can be selected only for a vdeo, s-vdeo and component vdeo sgnal.
• When ths adjustment s too large, certan degradaton may appear
at the frame area of the pcture. In such a case, please adjust small.
V POSITION
Using the ▲/▼ buttons adjusts the vertical position.
Up ó Down
• Over-adjustng the vertcal poston may cause nose to appear on the
screen. If ths occurs please reset the vertcal poston to the default settng.
Pressng the RESET button when the V POSITION s selected wll reset the
V POSITION to the default settng.
• When ths functon s performed on a vdeo sgnal, s-vdeo sgnal, or
component vdeo sgnal, the range of ths adjustment depends on the
OVER SCAN (above) settng. It s not possble to adjust when the OVER
SCAN s set to 10.
H POSITION
Using the ▲/▼ buttons adjusts the horizontal position.
Left ó Rght
• Over-adjustng the horzontal poston may cause nose to appear on the
screen. If ths occurs please reset the horzontal poston to the default
settng. Pressng the RESET button when the H POSITION s selected wll
reset the H POSITION to the default settng.
• When ths functon s performed on a vdeo sgnal, s-vdeo sgnal, or
component vdeo sgnal, the range of ths adjustment depends on the
OVER SCAN (above) settng. It s not possble to adjust when the OVER
SCAN s set to 10.
From the IMAGE menu, tems shown n the table below
can be performed.
Select an item using the ▲/▼ cursor buttons, and press
the ► cursor button or ENTER button to execute the item.
Then perform t accordng to the followng table.
/'07=%1/276'4?
+/#)'
2+%674'
5'.'%6
#761#&,756':'%76'
#52'%6
18'45%#0
*2*#5'
*5+<'
*215+6+10
8215+6+10
5'672
+0276
5%4''0
126+10
'#5;/'07
(contnued on next page)
