27 ViewSonic PJL3211
IMAGE Menu
Item Description
H PHASE
Using the ▲/▼ buttons adjusts the horizontal phase to eliminate flicker.
Rght ó Left
• Ths tem can be selected only for a computer sgnal or component
vdeo sgnal.
H SIZE
Using the ▲/▼ buttons adjusts the horizontal size.
Large ó Small
• Ths tem can be selected only for a computer sgnal.
• When ths adjustment s excessve, the pcture may not be
dsplayed correctly. In such a case, please reset the adjustment by
pressng the RESET button durng ths operaton.
AUTO ADJUST
EXECUTE
Selectng ths tem performs the automatc adjustment feature.
For a PC signal
The vertcal poston, the horzontal poston, the horzontal phase
and the horzontal sze (40) wll be automatcally adjusted. And
the aspect rato wll be automatcally set to the default.
Make sure that the applcaton wndow s set to ts maxmum sze
pror to attemptng to use ths feature. A dark pcture may stll be
ncorrectly adjusted. Use a brght pcture when adjustng.
For a video signal, s-video signal or component video signal
The vdeo format best suted for the respectve nput sgnal wll be
selected automatcally.
Ths functon s avalable only when the AUTO mode s selected to
the VIDEO FORMAT tem n INPUT menu (29).
The vertcal poston, horzontal poston and aspect rato wll be
automatcally set to the default.
For a component vdeo sgnal, also the horzontal phase wll be
automatcally set to the default.
• The automatc adjustment operaton requres about 10 seconds.
Also please note that t may not functon correctly wth some nput.
IMAGE Menu (continued)
