1-4 TallyGenicom Intelliprint 8026DN Color Laser Printer User Guide
Printer Location Requirements
Printer Location Requirements
Printer Weight and Dimensions
This printer weighs approximately 51 lbs (23 kg) and should always be lifted by two people. The
dimensions of the printer are listed below.
■
Printer Height: 16.3 in (413 mm)
■
Printer Width (left to right): 16.6 in (422 mm)
■
Printer Depth (front to back): 17.3 in (439 mm)
Minimum Installation Clearances
Be sure to install the printer in a location that respects the minimum clearances indicated in the
illustration below.
CAUTION
• The machine has ventilation holes on the left, right, and rear sides. Ensure that the machine
is installed with a minimum clearance of 100 mm (3.9") from the right side, 100 mm (3.9")
from the left side, and 100 mm (3.9") from the rear side. A poorly ventilated machine can
cause excessive internal heat and fire. The accompanying diagram shows the minimum
clearances required for normal operation, consumables replacement, and maintenance to
ensure your machine operates at peak performance.
350 mm
1'1.8"
457 mm
1'6.0"
100 mm
3.9"
580 mm
1'10.8"
600 mm
1'11.6"
100 mm
3.9"
429 mm
1'4.9"
100 mm
3.9"
