6-4 TallyGenicom Intelliprint 8026DN Color Laser Printer User Guide
Tray Module
Installing the Optional 550 Sheet Tray Module
1. Turn off the printer.
2. Lift the printer and align the four guide pins of the 550 sheet tray module with the holes at
the bottom of the printer. Gently lower the printer onto the optional 550 sheet tray module.
CAUTION
• To lift the printer safely, remove the drum cartridge and lift it with two people. Never try to lift
the printer while facing its right and left sides.
NOTE: Be careful not to pinch your fingers when lowering the printer onto the optional 550
sheet tray module.
3. Hold the upper side of the tray rear cover and pull it forward to remove it from the back of
the printer.
