Toshiba IK-WB30A User Manual
Page 97
97
Video clip: Select to send video clips when a trigger is activated.
■ Source: The source of video clip, which will be identical to the time shift caching stream. For more
information about time shift caching stream, please refer to page 60.
■ Pre-event recording
The Network Camera has a buffer area; it temporarily holds data up to a certain limit. Enter a number
to decide the duration of recording before a trigger is activated. Up to 9 seconds can be set.
■ Maximum duration
Specify the maximum recording duration in seconds. Up to 10 seconds can be set.
For example, if pre-event recording is set to five seconds and the maximum duration is set to ten
seconds, the Network Camera continues to record for another 4 seconds after a trigger is activated.
■ Maximum file size
Specify the maximum file size allowed.
■ File name prefix
Enter the text that will be appended to the front of the file name.
For example:
Click Save to enable the settings, then click Close to exit the page.
System log: Select to send a system log when a trigger is activated.
Click Save to enable the settings, then click Close to exit the page.
Video_
20100115_100341
Date and time suffix
The format is: YYYYMMDD_HHMMSS
File name prefix
1 sec.
2 sec.
3 sec.
4 sec.
5 sec.
6 sec.
7 sec.
8 sec.
9 sec.
10 sec.
Trigger Activation
