44
4. In the Networking Services dialog box, select Universal Plug and Play and click OK.
5. Click Next in the following window.
6. Click Finish. UPnP TM is enabled.
● How does UPnP TM work?
UPnP TM networking technology provides automatic IP configuration and dynamic discovery of devices
added to a network. Services and capabilities offered by networked devices, such as printing and file
sharing, are available among each other without the need for cumbersome network configuration. In
the case of Network Cameras, you will see Network Camera shortcuts under My Network Places.
● Enabling UPnP port forwarding allows the Network Camera to open a secondary HTTP port on the
router-not HTTP port-meaning that you have to add the secondary HTTP port number to the Network
Camera’s public address in order to access the Network Camera from the Internet. For example,
when the HTTP port is set to 80 and the secondary HTTP port is set to 8080, refer to the list below for
the Network Camera’s IP address.
From the Internet In LAN
http://203.67.124.123:8080 http://192.168.4.160 or
http://192.168.4.160:8080
● If the PPPoE settings are incorrectly configured or the Internet access is not working, restore the
Network Camera to factory default; please refer to Restore on page 108 for details. After the Network
Camera is reset to factory default, it will be accessible on the LAN.
