Screen Standards
External Monitor Support
The TravelMate 3000 WinSX supports all IBM standard VGA video in addition to 800 by
600, 1024 by 768, and 132column Paradise
TM
extended modes.
Paradise Modes Supported
Mode No.
(hex)
Resolution
Font
Clock
Memory
Size
132-column Text Modes (Supported on CRT only)*
54
32 x 43 x 16
8 x 8
44.7 MHz
256 KB
55
132 x 25 x 16
9x 16
44.7 MHz
256 KB
56
132 x 43 (mono)
8 x 8
44.7 MHz
256 KB
57
132 x 25 (mono)
9 x 16
44.7 MHz
256 KB
640 x 400 Modes
5E
640 x 400 x 256
9x 16
25 Mhz
256 KB
640 x 480 Modes
5F
640 x 480 x 256
9x 16
25 MHz
512 KB
800 x 600 Super VGA Modes (Supported on CRT only)
58/6A
800 x 600 x 16
8 x 8
44.7 MHz
256 KB
59/613
800 x 600 (mono)
8 x 8
44.7 MHz
256 KB
1024 x 768 Modes (Supported on CRT only)
5A
1024 x 768 x 2
9 x 16
44.7 MHz
256 KB
5B
1024 x 768 x 4
9x 16
44.7 MHz
256 KB
5D
1024 x 768 x 16
9 x 16
44.7 MHz
512 KB
*The 132-column text mode requires special software drivers; you should specify
PARADISE as the type of VGA controller. Some drivers are provided by TI, and some
are provided by application programs.
dag Super vGA modes are not supported on IBM PS/2 8503, 8512, 8513, or 8514
monitors or the equivalent fixed-frequency displays (the 8503 is a monochrome display).
The vertical and horizontal size and position controls on monitors can be adjusted to
display the entire 800-by-600 graphics mode Image without distortion.
H-4 Screen Standards
