Specifications – Texas Instruments 3000 WinSX User Manual
Page 134
Specifications
Physical Dimensions
Size
Width:
1 1 inches (279 mm)
Depth:
8.5 inches (216 mm)
Height:
1.8 inches (46 mm)
Weight:
5.7 lbs (2.6 kg), including battery,
without options
Power Source
NiCad battery:
24 watt hours
AC Adapter
Input:
100 to 250 Vac, 0.7 to 0.4 A,
50 to 60 Hz
Output:
+5 Vdc, 3.5 A max
+7 Vdc, 1. 5 A max
+8.5 Vdc, 1. 5 A max
Total output not to exceed 3.8 A
Temperature
Operating:
50
o
to 95
o
F (10
o
to 35
o
C)
Storage/Transit:
-4
o
to 140
o
F (-20
o
to 60
o
C
Humidity
Operating:
20% to 80%, non-condensing
Storage/Transit:
10% to 90%, non-condensing
Vibration
Operating:
0.5 G, 5 to 250 Hz
Storage/Transit:
5.0 G, 5 to 250 Hz
A-2 Specifications
