Diagnostics
The following table lists the classes of error codes. The numbers are in hexadecimal.
Diagnostics Error Code Classes
Code Description
01q System planar board tests
07q Keyboard tests
10q Math coprocessor tests
17q Video tests
20q Asynchronous ports tests
27q LPT ports tests
30q Memory tests
37q Diskette/Fdisk tests
The following table lists the error codes that could be displayed by the diagnostics
program. The codes are displayed by class, followed by sub-class.
Diagnostics Program Error Codes
Code Class Failure
Description
0101 System board DMA registers
0102 System board DMA memory
move
0103 System board Interrupt mask
0104 System board Hot interrupt line
0105 System board Stuck NMI
0106 System board Processor registers
Diagnostics D-7
