TOSHIBA
4.3.1
Recommended Wire Size and Torque Requirements For UPS Input and
Output
Terminals
Minimum Wire Size and Torque Requirements
UPS Input and Output Terminals 50 kVA
(USE MINIMUM 75 °C INSULATED COPPER WIRING)
INPUT:
OUTPUT:
(H1) (H2) (H3)
AWG
(L1)(L2)(L3)
Tightening
NEUTRAL
AWG
AWG
NEUTRAL
AWG
Torque
208 V
1/0
250MCM
208/120 V
1/0
250MCM
200 in-lbs.
220 V
1/0
4/0
220/127 V
1/0
4/0
200 in-lbs.
240 V
1
N/A
240 V
1
N/A
200 in-lbs.
380 V
4
1/0
380/220 V
4
1/0
200 in-lbs.
400 V
4
1/0
400/230 V
4
1/0
200 in-lbs.
415 V
4
1
415/240 V
4
1
200 in-lbs.
480 V
6
2
480/277 V
6
2
200 in-lbs.
600 V
6
N/A
600 V
6
N/A
200 in-lbs.
All wire sizes are per the NEC. Maximum Wire Size for Input and Output is 1/0 AWG.
Neutral Conductors are rated @ 1.73 or 200% of phase conductors, per NEC. Maximum Wire Size for Neutral
is 250MCM.
50 kVA
Input/ Output (GND)
AWG
Tightening Torque
208-240 VAC
6
200 in-lbs.
380-480 VAC
6
200 in-lbs.
600 VAC
8
200 in-lbs.
Battery (+) / (-)
50 kVA
AWG
Tightening Torque
(+) (-)
250MCM
200 in-lbs.
Maximum Wire Size for Battery is 250MCM.
Minimum Wire Size and Torque requirements
UPS Optional Bypass Input Terminals TB4 50 kVA
(USE MINIMUM 75 °C INSULATED COPPER WIRING)
50 kVA
Phase: (A) (B) (C)
Input: (H1) (H2) (H3)
AWG
NEUTRAL AWG
Tightening Torque
208/120 V
1/0
250MCM
200 in-lbs.
220 V
1/0
4/0
200 in-lbs.
240 V
1
N/A
200 in-lbs.
380 V
4
1/0
200 in-lbs.
400 V
4
1/0
200 in-lbs.
415 V
4
1
200 in-lbs.
480 V
6
2
200 in-lbs.
600 V
6
N/A
200 in-lbs.
Maximum Wire Size for Input is 1/0 AWG. Maximum Wire Size for Neutral is 250MCM.
