Television System
NTSC standard
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
213 W (average)
Audio Power
Main : 20 W + 20 W
Woofer : 20 W + 20 W
Speaker Type
Main : Two 2-3/16 × 6 inches (50 × 150 mm)
Woofer : Two 5-1/2 inches (140 mm) round
Video/Audio Terminals
S-VIDEO INPUT
Y : 1 V(p-p), 75 ohm, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
47 kohm)
ColorStream ® (component video) INPUT
Y : 1V(p-p), 75 ohm
P
R : 0.7 V(p-p), 75 ohm
P B : 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 47 kohm
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
4.7 kohm)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent, 4.7 kohm)
AUDIO CENTER CHANNEL INPUT
300 mV(rms) (30% modulation equivalent, 10 kohm)
DVI/HDCP INPUT
HDCP compliant
E-EDID* 1.3 compliant
DVI-D uncompressed, high-speed, digital single-link
connection
Suggested input scan rates: 1080i, 720p, 480p, 480i
Specifications
Design and specifications are subject to change without notice.
PC INPUT
Mini D-sub 15-pin, Analog RGB
DIGITAL AUDIO INPUT
Optical or Coaxial
IR Blaster
OUTPUT: 3 V(p-p), 10 kohm
INPUT:
3 V(p-p) to 5 V(p-p), pulse code modulated
(Toshiba TV code) over 38 KHz carrier
Dimensions
Width : 62-3/4 inches (1592.4 mm)
Height : 60-1/4 inches (1530.6 mm)
Depth : 18-1/2 inches (470 mm)
Weight
300 lbs (136.1 kg)
Supplied Accessories
Remote Control with 2 size “AA” alkaline batteries
Illumination lamp (for replacement)
___________
*E-EDID = Enhanced-Extended Display Identification
