Weights – Trane WSC060-120 User Manual
Page 46
46
PKGP-PRC004-EN
Weights
Table W-1 — Maximum Unit and Corner Weights And Center Of Gravity Dimensions (SI)
Maximum Weights
2
(kg)
Corner Weights
1
(kg)
Center of Gravity (mm)
Unit Model No.
Shipping
2
Net
2
A
B
C
D
Length
Width
WSC060AD,T
276
241
77
58
49
58
790
480
WSC072AD,T
416
368
122
93
66
87
970
560
WSC090AD,T
426
378
128
95
67
88
970
530
WSC120AD,T
493
445
150
115
78
102
970
530
Notes:
1. Corner weights are given for information only. All models must be supported continuously by a curb or equivalent frame support.
2. Weights are approximate.
Table W-1a — Maximum Unit and Corner Weights And Center Of Gravity Dimensions (IP)
Maximum Weights (lbs)
Corner Weights
1
(lbs)
Center of Gravity (in)
Unit Model No.
Shipping
2
Net
A
B
C
D
Length
Width
WSC060AD,T
586
532
170
128
107
127
31
19
WSC072AD,T
899
812
269
206
146
191
38
22
WSC090AD,T
921
834
282
210
147
195
38
21
WSC120AD,T
1068
980
330
253
172
225
38
21
Notes:
1. Corner weights are given for information only. All models must be supported continuously by a curb or equivalent frame support.
2. Weights are approximate.
Table W-2 — Accessory Net Weights
1, 2
(kg)
Net Weights
2
Accessory
3
WSC060
WSC072-120
Economizer
12
16
Barometric Relief
3
5
Motorized Outside Air Damper
9
14
Manual Outside Air Damper
7
12
Roof Curb
32
52
Oversized Motor
2
4
Coil Guards
5
9
Hinged Doors
5
5
Electric Heaters
7
14
Notes:
1. Weights for options not listed are < 3 kg.
2. Net weight should be added to unit weight when ordering factory-
installed accessories.
3. Some accessories not available on all units.
Table W-2a — Accessory Net Weights
1, 2
(lbs)
Net Weights
2
Accessory
3
WSC060
WSC072-120
Economizer
26
36
Barometric Relief
7
10
Motorized Outside Air Damper
20
30
Manual Outside Air Damper
16
26
Roof Curb
70
115
Oversized Motor
5
8
Coil Guards
12
20
Hinged Doors
10
12
Electric Heaters
15
30
Notes:
1. Weights for options not listed are < 5 lbs.
2. Net weight should be added to unit weight when ordering factory-
installed accessories.
3. Some accessories not available on all units.
