Table PD-4 — Gross Cooling Capacities (kW) WSC120AD,T (SI)
Enter.
Ambient Temperature (C)
Dry
30
35
40
45
Bulb
Entering Wet Bulb Temperature (C)
m
3
/h
Temp
16
19
22
16
19
22
16
19
22
16
19
22
Airflow
(C)
TGC SHC
TGC SHC TGC SHC
TGC
SHC
TGC SHC TGC SHC
TGC SHC TGC SHC
TGC SHC
TGC SHC
TGC SHC
TGC SHC
6120
24
31.0 27.0
35.1 21.7 37.3 15.9
29.0
26.0
33.3 20.8 36.4 15.3
26.8 24.9 31.0 19.8
35.0 14.5
24.2 24.2
28.4 19.9
33.1 13.7
27
32.3 31.9
35.2 27.2 37.6 21.2
30.4
30.4
33.4 26.3 36.6 20.7
28.6 28.6 31.1 25.3
35.1 20.0
26.8 26.8
28.7 24.2
33.1 19.1
30
34.6 34.6
35.6 32.6 38.0 26.0
33.1
33.1
33.9 32.0 36.8 25.7
31.4 31.4 31.3 31.3
35.2 25.3
29.5 29.5
29.8 29.2
33.2 24.6
33
36.6 36.6
36.6 36.5 38.2 30.6
35.4
35.4
35.4 35.4 37.1 30.8
33.9 33.9 33.9 33.9
35.5 30.6
32.2 32.2
32.2 32.2
33.6 30.0
6800
24
31.9 28.7
35.6 22.7 37.6 16.2
29.8
27.6
33.9 21.8 36.7 15.9
27.1 27.1 31.7 20.8
35.4 15.0
25.2 25.2
29.1 19.7
33.6 14.1
27
33.4 33.4
35.8 28.5 37.9 21.7
31.7
31.7
34.1 27.9 36.9 22.8
29.9 29.9 31.9 26.9
35.5 20.9
28.0 28.0
29.5 25.8
33.6 20.1
30
35.8 35.8
36.3 34.3 38.2 26.6
34.4
34.4
34.4 34.4 37.2 26.7
32.7 32.7 33.0 32.2
35.7 26.6
30.8 30.8
30.9 30.8
33.8 26.0
33
37.5 37.5
37.5 37.5 38.6 30.7
36.4
36.4
36.4 36.4 37.6 32.1
35.1 35.1 35.0 35.0
36.1 32.2
33.5 33.5
33.5 33.5
34.3 31.8
7480
24
32.7 30.3
36.0 23.5 37.9 16.8
30.0
30.0
34.4 22.8 36.9 16.2
28.1 28.1 32.2 21.8
35.6 15.7
26.3 25.9
29.7 20.7
33.9 14.5
27
34.5 34.5
36.3 29.7 38.2 22.2
32.9
32.9
34.7 29.3 37.1 22.1
31.0 31.0 32.5 28.4
35.8 21.6
29.1 29.1
30.2 27.4
34.1 21.0
30
36.6 36.6
36.6 36.6 38.5 27.5
35.4
35.4
35.3 35.3 37.5 27.6
33.8 33.8 33.9 33.6
36.1 27.6
32.0 32.0
32.0 32.0
34.3 27.3
33
38.1 38.1
38.1 38.1 38.9 32.5
37.2
37.2
37.2 37.2 37.9 33.2
35.9 35.9 35.9 35.9
36.6 33.6
34.4 34.4
34.4 34.4
34.4 34.4
8160
24
32.8 32.8
36.3 24.2 37.9 17.1
30.9
30.9
34.8 23.7 37.1 16.8
29.0 29.0 32.7 22.7
35.9 16.1
26.9 26.9
30.2 21.6
34.2 14.9
27
35.4 35.4
36.7 30.8 38.4 22.5
33.9
33.9
35.1 30.6 37.4 22.6
32.0 32.0 33.1 29.9
36.1 22.2
30.0 30.0
30.8 28.9
34.4 21.8
30
37.2 37.2
37.2 37.2 38.9 28.1
36.1
36.1
36.1 35.7 37.7 28.4
34.7 34.7 34.6 34.6
36.4 28.6
32.9 32.9
32.9 32.9
34.7 28.4
33
38.6 38.6
38.5 38.5 39.4 33.8
37.7
37.7
37.7 37.7 38.2 34.2
36.6 36.6 36.6 36.6
37.0 34.7
35.1 35.1
35.1 35.1
35.1 35.1
Notes:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling, subtract indoor fan heat.
2. TGC = Total Gross Capacity
3. SHC = Sensible Heat Capacity
Table PD-4a — Gross Cooling Capacities (MBH) WSC120AD,T (IP)
Enter.
Ambient Temperature (F)
Dry
85
95
105
115
Bulb
Entering Wet Bulb Temperature (F)
CFM
Temp
61
67
73
61
67
73
61
67
73
61
67
73
Airflow
(F)
TGC SHC
TGC SHC TGC SHC
TGC
SHC
TGC SHC TGC SHC
TGC SHC TGC SHC
TGC SHC
TGC SHC
TGC SHC
TGC SHC
3600
75
107.1 91.1 121.9 71.0 128.7 47.6
99.2
87.2 115.7 67.7 125.5 45.7
91.0 83.1 107.0 67.2 120.9 43.4
80.7 80.7
97.5 63.2 114.4 40.5
80
109.1 109.1 122.1 88.0 130.0 66.8 103.3 102.4 115.9 85.0 126.5 63.3
96.0 96.0 107.5 81.2 121.4 60.7
89.0 89.0
98.1 77.1 114.6 57.7
85
117.2 117.2 123.0 104.8 131.4 80.1 111.2 111.2 116.8 102.7 127.3 78.9 104.6 104.6 108.8 99.1 121.7 77.5
97.5 97.5 100.1 95.2 114.9 74.8
90
123.7 123.7 123.6 123.6 132.5 94.8 118.9 118.9 118.8 118.8 128.1 94.3 112.9 112.9 113.2 112.8 122.6 93.8 106.1 106.1 106.1 106.1 115.4 91.8
4000
75
110.0 96.6 123.5 73.7 129.3 48.4 101.9 92.6 117.7 70.7 126.3 46.5
93.6 88.6 109.4 67.0 121.9 44.2
84.1 84.1
99.8 62.9 115.8 41.4
80
114.1 113.0 123.9 91.8 130.8 66.7 107.2 107.2 118.0 89.7 127.5 65.8 100.2 100.2 109.9 86.1 122.7 63.2
92.9 92.9 100.5 82.1 116.1 60.2
85
121.2 121.2 125.0 109.8 132.3 82.0 115.8 115.8 119.2 108.7 128.3 82.0 109.2 109.2 111.8 105.8 123.2 80.7 102.0 102.0 101.9 101.9 116.6 78.9
90
126.8 126.8 126.8 126.8 133.8 97.6 122.6 122.6 122.7 122.1 129.4 97.7 117.2 117.2 117.1 117.1 124.2 98.1 110.7 110.7 110.6 110.6 117.4 97.0
4400
75
112.5 101.9 124.4 77.0 129.8 49.0 104.5 98.0 119.3 73.6 127.0 47.1
94.7 94.7 111.3 70.0 122.7 45.1
87.9 86.2 101.8 65.9 116.8 42.1
80
117.5 117.5 125.3 95.1 131.4 67.5 111.1 111.1 119.7 93.9 128.3 70.3 104.0 104.0 112.0 90.7 123.6 65.8
96.5 96.5 102.7 86.8 117.3 62.6
85
124.1 124.1 126.6 114.1 133.0 83.5 119.3 119.3 121.3 114.1 129.9 84.1 113.0 113.0 113.0 113.0 124.3 83.3 105.8 105.8 106.7 104.3 117.8 82.2
90
129.1 129.1 129.0 129.0 134.5 99.7 125.4 125.4 125.3 125.3 131.4 100.4 120.3 120.3 120.3 120.3 125.5 101.8 114.2 114.2 114.2 114.2 119.0 101.6
4800
75
114.7 106.9 125.4 79.1 130.3 49.6 105.1 105.1 120.5 76.3 127.4 48.1
97.7 97.7 112.9 72.8 123.3 46.0
90.3 89.8 103.4 68.7 117.6 43.0
80
120.3 120.3 126.4 98.0 131.9 68.3 114.4 114.4 121.2 97.7 129.0 68.0 107.3 107.3 113.8 95.2 124.2 66.4
99.6 99.6 104.6 91.3 118.3 64.8
85
126.3 126.3 127.8 117.8 133.5 84.7 121.9 121.9 121.9 121.9 130.5 86.0 116.1 116.1 116.1 116.1 125.4 85.7 109.1 109.1 109.4 108.7 118.9 85.2
90
131.1 131.1 130.6 130.6 135.1 101.6 127.4 127.4 127.3 127.3 131.3 103.4 122.7 122.7 122.7 122.7 126.6 105.0 116.9 116.9 116.9 116.9 120.3 105.6
Notes:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling, subtract indoor fan heat.
2. TGC = Total Gross Capacity
3. SHC = Sensible Heat Capacity
