PKGP-PRC004-EN 35
Electrical
Data
Table ED-1 — Unit Wiring
Standard Indoor Fan Motor Oversize Indoor Fan Motor
Unit Minimum Maximum Fuse Minimum Maximum Fuse
Unit Operating Circuit Size Or Maximum Circuit Size Or Maximum
Model No. Voltage Range Ampacity Circuit Breaker 1 Ampacity Circuit Breaker 1
WSC060AD 342-456 18.9 25 18.9 25
WSC060AT 180-220 37.2 50 37.2 50
WSC072AD 342-456 21.9 30 22.9 30
WSC072AT 180-220 38.4 60 43.9 60
WSC090AD 342-456 24.8 35 26.5 35
WSC090AT 180-220 47.6 60 50.2 60
WSC120AD 342-456 31.2 40 31.2 40
WSC120AT 180-220 59.5 60 59.5 60
Notes:
1. All units to be installed under local codes.
