Performance data – Trane WSC060-120 User Manual
Page 32
32
PKGP-PRC004-EN
Performance
Data
Table PD-24 — Auxiliary Electric Heat Capacity
Total
2
Stage 1
Stage 2
Unit
Model No.
kW
No. Stages
kW
kW
8.3
2
4.2
4.2
WSC060AT
12.1
2
6.0
6.0
16
2
9.9
6.0
7.5 / 9.0
2
3.75 / 4.5
3.75 / 4.5
WSC060AD
10.9 / 13.0
2
5.45 / 6.5
5.45 / 6.5
14.4 / 17.2
2
8.95 / 10.7
5.45 / 6.5
12.5
1
12.5
WSC072AT
18.8
2
12.5
6.3
25
2
12.5
12.5
11.3 / 13.5
1
11.3 / 13.5
—-
WSC072AD
16.9 / 20.2
2
11.3 / 13.5
5.6 / 6.7
22.6 / 26.9
2
11.3 / 13.5
11.3 / 13.5
12.5
1
12.5
WSC090AT
18.8
2
12.5
6.3
25
2
12.5
12.5
11.3 / 13.5
1
11.3 / 13.5
—-
WSC090AD
16.9 / 20.2
2
11.3 / 13.5
5.6 / 6.7
22.6 / 26.9
2
11.3 / 13.5
11.3 / 13.5
18.8
2
12.5
6.3
WSC120AT
25
2
12.5
12.5
37.5
2
25.0
12.5
16.9 / 20.2
2
11.3 / 13.8
5.6 / 6.7
WSC120AD
22.6 / 26.9
2
11.3 / 13.9
11.3 / 13.5
33.9 / 40.4
2
11.3 / 13.10
22.5 / 26.9
Notes:
1. Does not include indoor fan power or heat
2. Heaters are rated at 200V, and 380V / 415V. For other than rated voltage, CAP = (Voltage/Rated Voltage)
2
x Rated Cap.
Table PD-24a — Auxiliary Electric Heat Capacity
Total
2
Stage 1
Stage 2
Unit
Model No.
MBH
No. Stages
MBH
MBH
28
2
14
14
WSC060AT
41
2
20
20
55
2
34
20
26 / 31
2
13 / 16
13 / 16
WSC060AD
38 / 45
2
19 / 23
19 / 23
50 / 59
2
31 / 37
19 / 23
43
1
43
—-
WSC072AT
64
2
43
22
85
2
43
43
39 / 47
1
39 / 47
—-
WSC072AD
58 / 69
2
39 / 47
20 / 23
78 / 92
2
39 / 47
39 / 47
43
1
43
—-
WSC090AT
64
2
43
22
85
2
43
43
39 / 47
1
39 / 47
—-
WSC090AD
58 / 69
2
39 / 47
20 / 23
78 / 92
2
39 / 47
39 / 47
64
2
43
22
WSC120AT
85
2
43
43
123
2
85
43
58 / 69
2
39 / 47
20 / 23
WSC120AD
78 / 92
2
39 / 47
39 / 47
116 / 138
2
39 / 47
77 / 92
Notes:
1. Does not include indoor fan power or heat
2. Heaters are rated at 200V, and 380V / 415V. For other than rated voltage, CAP = (Voltage/Rated Voltage)
2
x Rated Cap.
