Performance
Data
Table PD-10 — Belt Drive Evaporator Fan Performance WSC060AD,T Horizontal Configuration (SI)
External Static Pressure (Pascals)
25 50 75 100 125 150 175 200 225 250
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
1.12 Nom kW Standard Motor & Low Static Drive 1.12 Nom kW Standard Motor & Drive
2720 692 0.25 761 0.30 823 0.36 884 0.41 941 0.47 990 0.52 1034 0.58 1077 0.64 1119 0.70 1158 0.75
3060 761 0.35 825 0.40 882 0.46 937 0.52 992 0.58 1043 0.65 1088 0.71 1130 0.77 1169 0.83 1207 0.90
3400 831 0.46 891 0.52 945 0.58 995 0.65 1045 0.72 1094 0.79 1141 0.86 1185 0.93 1224 1.00 1260 1.07
3740 901 0.60 958 0.67 1009 0.73 1057 0.80 1101 0.88 1146 0.95 1192 1.03 1235 1.11 1277 1.18 1314 1.26
4080 972.8 0.76 1026 0.84 1075 0.91 1120 0.98 1163 1.06 1204 1.14 1245 1.23 — — — — — —
1.12 Nom kW Standard Motor &
Hi Static Drive
Factory Supplied Motors, In Commercial Equipment, Are Definite Purpose
Motors, Specifically Designed And Tested To Operate Reliably And
Continuously At All Cataloged Conditions. Using The Full Horsepower
Range Of Our Fan Motors As Shown In Our Tabular Data Will Not Result In
Nuisance Tripping Or Premature Motor Failure. Our Product’s Warranty
Will Not Be Affected.
External Static Pressure (Pascals)
275 300 325 350 375
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW
1.12 Nom kW Standard Motor 1.12 Nom kW Standard Motor &
& Drive Hi Static Drive
2720 1196 0.82 1231 0.88 1265 0.94 1298 1.00 1330 1.07
3060 1244 0.96 1280 1.03 1314 1.10 1346 1.16 1380 1.24
3400 1295 1.14 1330 1.21 1363 1.28 — — — —
3740 — — — — — — — — — —
4080 — — — — — — — — — —
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
1.12 kW - Fan Motor Heat (kW) = 1.144 x Fan kW + 0.132
Table PD-10a — Belt Drive Evaporator Fan Performance WSC060AD,T Horizontal Configuration (IP)
External Static Pressure (Inches of Water)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-1/2 HP Standard Motor & Low Static Drive 1-1/2 HP Standard Motor & Drive
1600 692 0.34 761 0.41 823 0.48 884 0.55 941 0.63 990 0.70 1034 0.78 1077 0.85 1119 0.93 1158 1.01
1800 761 0.47 825 0.54 882 0.62 937 0.70 992 0.78 1043 0.87 1088 0.95 1130 1.03 1169 1.12 1207 1.21
2000 831 0.62 891 0.70 945 0.78 995 0.87 1045 0.97 1094 1.06 1141 1.15 1185 1.25 1224 1.34 1260 1.43
2200 901 0.80 958 0.90 1009 0.98 1057 1.08 1101 1.18 1146 1.28 1192 1.38 1235 1.49 1277 1.59 1314 1.69
2400 972.8 1.02 1026 1.13 1075 1.22 1120 1.32 1163 1.42 1204 1.53 1245 1.65 — — — — — —
1-1/2 HP Standard Motor & Drive
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-1/2 HP Std Motor & Drive 1-1/2 HP Standard Motor & Hi Static Drive
1600 1196 1.09 1231 1.17 1265 1.26 1298 1.35 1330 1.44
1800 1244 1.29 1280 1.38 1314 1.47 1346 1.56 1380 1.66
2000 1295 1.52 1330 1.62 1363 1.72 — — — —
2200 — — — — — — — — — —
2400 — — — — — — — — — —
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
1 1/2 HP - Fan Motor Heat (MBH) = 2.915 x Fan BHP + 0.451
Factory Supplied Motors, In Commercial Equipment,
Are Definite Purpose Motors, Specifically Designed And Tested To
Operate Reliably And Continuously At All Cataloged Conditions.
Using The Full Horsepower Range Of Our Fan Motors As Shown In
Our Tabular Data Will Not Result In Nuisance Tripping Or Premature
Motor Failure. Our Product’s Warranty Will Not Be Affected.
1-1/2 HP Standard Motor & Hi Static Drive
