PKGP-PRC004-EN
Electrical
Data
Table ED-2 — Unit Wiring With Electric Heat Single Point Connection — 380–415 Volts
Standard Indoor Fan Motor
Oversized Indoor Fan Motor
Minimum
Maximum Fuse
Minimum
Maximum Fuse
Unit
Heater
Heater
2
Control
Circuit
Size Or Maximum
Circuit
Size Or Maximum
Model No.
Model No.
kW Rating
MBH
Stages
Ampacitiy
Circuit Breaker
1
Ampacitiy
Circuit Breaker
1
380 / 415 Volts
BAYHTRR412A
7.5 / 9.0
26 / 31
2
33.3 / 34.6
40 / 40
—
—
WSC060AD
BAYHTRR418A
10.9 / 13.0
38 / 45
2
39.7 / 41.6
45 / 45
—
—
BAYHTRR423A
14.4 / 17.2
50 / 59
2
46.3 / 48.8
50 / 50
—
—
BAYHTRS418A
11.3 / 13.5
39 / 47
1
43.4 / 45.4
50 / 50
44.4 / 46.4
50 / 50
WSC072AD
BAYHTRS427A
16.9 / 20.2
58 / 69
2
54.1 / 57.1
60 / 60
55.1 / 58.1
60 / 60
BAYHTRS436A
22.6 / 26.9
78 / 92
2
64.8 / 68.7
70 / 70
65.8 / 69.7
70 / 70
BAYHTRS418A
11.3 / 13.5
39 / 47
1
46.3 / 48.3
50 / 50
48.0 / 50.0
50 / 50
WSC090AD
BAYHTRS427A
16.9 / 20.2
58 / 69
2
56.9 / 59.9
60 / 60
58.6 / 61.6
60 / 60
BAYHTRS436A
22.6 / 26.9
78 / 92
2
67.7 / 71.6
70 / 70
69.4 / 73.3
70 / 70
BAYHTRT427A
16.9 / 20.2
58 / 69
2
63.3 / 66.3
70 / 70
—
—
WSC120AD
BAYHTRT436A
22.6 / 26.9
78 / 92
2
74.0 / 77.9
80 / 80
—
—
BAYHTRT454A
33.9 / 40.4
116 / 138
2
95.5 / 101.4
100 / 110
—
—
Notes:
1. All units to be installed under local codes
2. kW shown for 380V / 415V
Table ED-3 — Unit Wiring With Electric Heat Single Point Connection — 200 Volts
Standard Indoor Fan Motor
Oversized Indoor Fan Motor
Minimum
Maximum Fuse
Minimum
Maximum Fuse
Unit
Heater
Heater
2
Control
Circuit
Size Or Maximum
Circuit
Size Or Maximum
Model No.
Model No.
kW Rating
MBH
Stages
Ampacitiy
Circuit Breaker
1
Ampacitiy
Circuit Breaker
1
200 Volts
BAYHTRR312AA
8.3
28
2
67.2
80
—
—
WSC060AT
BAYHTRR318AA
12.1
41
2
80.9
90
—
—
BAYHTRR323AA
16.0
55
2
95.0
100
—
—
BAYHTRS318AA
12.5
43
1
86.4
100
89.1
100
WSC072AT
BAYHTRS327AA
18.8
64
2
109.1
110
111.8
125
BAYHTRS336AA
25.0
85
2
131.5
150
134.2
150
BAYHTRS318AA
12.5
43
1
92.7
100
95.3
100
WSC090AT
BAYHTRS327AA
18.8
64
2
115.4
125
118.0
125
BAYHTRS336AA
25.0
85
2
137.8
150
140.4
150
BAYHTRT327AA
18.8
64
2
127.4
150
—
—
WSC120AT
BAYHTRT336AA
25.0
85
2
149.7
150
—
—
BAYHTRT354AA
37.5
123
2
194.9
200
—
—
Notes:
1. All units to be installed under local codes
2. kW shown for 380V / 415V
