22 PKGP-PRC004-EN
Performance
Data
Factory Supplied Motors, In Commercial Equipment, Are
Definite Purpose Motors, Specifically Designed And Tested To
Operate Reliably And Continuously At All Cataloged Conditions.
Using The Full Horsepower Range Of Our Fan Motors As Shown
In Our Tabular Data Will Not Result In Nuisance Tripping Or
Premature Motor Failure. Our Product’s Warranty Will Not Be
Affected.
External Static Pressure (Pascals)
275 300 325 350 375
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW
1.12 Nom kW Standard Motor & Drive
2720 1085 0.68 1118 0.72 1151 0.78 1183 0.83 1214 0.88
3060 1128 0.80 1160 0.86 1192 0.91 1223 0.97 1252 1.02
3400 1170 0.93 1203 1.00 1235 1.06 1265 1.12 1295 1.19
3740 1212 1.07 1244 1.14 1276 1.21 1308 1.29 — —
4080 1256 1.26 1287 1.32 — — — — — —
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
1.12 kW - Fan Motor Heat (kW) = 1.144 x Fan kW + 0.132
1.12 Nom kW Standard Motor &
Hi Static Drive
Table PD-9 — Belt Drive Evaporator Fan Performance WSC060AD,T Downflow Configuration (SI)
External Static Pressure (Pascals)
25 50 75 100 125 150 175 200 225 250
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
1.12 Nom kW Standard Motor & Low Static Drive 1.12 Nom kW Standard Motor & Drive
2720 — — 690 0.26 746 0.30 795 0.34 843 0.38 889 0.42 933 0.47 975 0.53 1014 0.58 1050 0.63
3060 693 0.31 746 0.34 802 0.39 848 0.44 892 0.48 935 0.52 976 0.57 1016 0.62 1056 0.68 1093 0.74
3400 758 0.41 806 0.45 856 0.50 904 0.55 945 0.60 985 0.65 1023 0.70 1061 0.75 1098 0.80 1135 0.86
3740 824 0.54 869 0.58 913 0.63 959 0.68 1001 0.74 1038 0.80 1074 0.85 1109 0.90 1143 0.96 1177 1.01
4080 890 0.69 933 0.74 972 0.78 1014 0.84 1056 0.90 1094 0.97 1128 1.03 1160 1.09 1193 1.15 1225 1.20
Factory Supplied Motors, In Commercial Equipment,
Are Definite Purpose Motors, Specifically Designed And Tested To
Operate Reliably And Continuously At All Cataloged Conditions.
Using The Full Horsepower Range Of Our Fan Motors As Shown In
Our Tabular Data Will Not Result In Nuisance Tripping Or Premature
Motor Failure. Our Product’s Warranty Will Not Be Affected.
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1–1/2 HP Standard Motor & Drive
1600 1085 0.91 1118 0.97 1151 1.04 1183 1.11 1214 1.18
1800 1128 1.08 1160 1.15 1192 1.22 1223 1.29 1252 1.37
2000 1170 1.25 1203 1.34 1235 1.43 1265 1.51 1295 1.59
2200 1212 1.44 1244 1.53 1276 1.63 1308 1.73 — —
2400 1256 1.69 1287 1.77 — — — — — —
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
1 1/2 HP - Fan Motor Heat (MBH) = 2.915 x Fan BHP + 0.451
1–1/2 HP Standard Motor &
Hi Static Drive
Table PD-9a — Belt Drive Evaporator Fan Performance WSC060AD,T Downflow Configuration (IP)
External Static Pressure (Inches of Water)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1–1/2 HP Standard Motor & Low Static Drive 1–1/2 HP Standard Motor & Drive
1600 — — 690 0.35 746 0.40 795 0.46 843 0.51 889 0.57 933 0.64 975 0.71 1014 0.78 1050 0.84
1800 693 0.41 746 0.46 802 0.52 848 0.59 892 0.65 935 0.70 976 0.76 1016 0.84 1056 0.92 1093 1.00
2000 758 0.56 806 0.60 856 0.67 904 0.74 945 0.81 985 0.87 1023 0.94 1061 1.00 1098 1.07 1135 1.16
2200 824 0.73 869 0.78 913 0.84 959 0.92 1001 1.00 1038 1.07 1074 1.15 1109 1.21 1143 1.28 1177 1.35
2400 890 0.93 933 0.99 972 1.05 1014 1.12 1056 1.21 1094 1.30 1128 1.38 1160 1.46 1193 1.54 1225 1.61
1-1/2 HP Standard Motor & Static Drive
