Table PD-2 — Gross Cooling Capacities (kW) WSC072AD,T (SI)
Enter.
Ambient Temperature (C)
Dry
30
35
40
45
Bulb
Entering Wet Bulb Temperature (C)
m
3
/h
Temp
16
19
22
16
19
22
16
19
22
16
19
22
Airflow
(C)
TGC SHC
TGC SHC TGC SHC
TGC
SHC
TGC SHC TGC SHC
TGC SHC TGC SHC
TGC SHC
TGC SHC
TGC SHC
TGC SHC
3670
24
20.3 18.1
22.7 14.4 23.9 10.2
19.0
17.4
21.7 14.0 23.6
9.9
17.6 16.7 20.2 13.4
22.9
9.6
16.1 16.0
18.6 12.7
21.7
9.2
27
21.2 21.2
22.8 17.9 24.2 13.6
20.1
20.1
21.8 17.6 23.7 13.6
19.0 19.0 20.4 17.0
22.9 13.3
17.7 17.7
18.8 16.3
21.7 12.9
30
22.6 22.6
23.1 21.5 24.4 16.7
21.9
21.9
22.2 21.5 23.8 16.8
20.8 20.8 20.9 20.9
23.0 16.8
19.5 19.5
19.5 19.5
21.8 16.5
33
23.7 23.7
23.7 23.7 24.6 19.9
23.2
23.2
23.2 23.2 24.1 20.2
22.4 22.4 22.4 22.4
23.2 20.4
21.3 21.3
21.3 21.3
22.1 20.3
4080
24
20.9 19.3
23.0 15.1 24.1 10.4
19.5
18.6
22.2 14.6 23.8 10.2
18.1 17.9 20.7 14.0
23.1
9.8
16.7 16.7
19.0 13.5
22.1
9.5
27
22.1 22.1
23.1 18.8 24.3 13.8
21.0
21.0
22.3 18.7 23.9 13.9
19.8 19.8 20.9 18.2
23.2 13.9
18.6 18.6
19.3 17.5
22.1 13.5
30
23.3 23.3
23.5 22.5 24.6 17.1
22.7
22.7
22.6 22.6 24.1 17.5
21.7 21.7 21.7 21.7
23.3 17.7
20.5 20.5
20.5 20.5
22.2 17.6
33
24.2 24.2
24.2 24.2 24.8 20.5
23.8
23.8
23.8 23.8 24.4 21.0
23.1 23.1 23.1 23.1
23.6 21.5
22.2 22.2
22.2 22.2
22.5 21.5
4490
24
21.4 20.4
23.2 15.6 24.2 10.7
20.1
19.8
22.5 15.3 23.9 10.4
18.7 18.7 21.1 14.7
23.3 10.1
17.3 17.3
19.3 14.3
22.3
9.7
27
22.6 22.6
23.4 19.5 24.5 14.2
21.8
21.8
22.6 19.7 24.2 14.4
20.6 20.6 21.3 19.3
23.4 14.3
19.3 19.3
19.8 18.6
22.4 14.2
30
23.7 23.7
23.8 23.4 24.8 17.7
23.2
23.2
23.2 23.2 24.3 18.1
22.4 22.4 22.4 22.4
23.6 18.5
21.2 21.2
21.2 21.2
22.5 18.5
33
24.5 24.5
24.5 24.5 25.1 21.2
24.2
24.2
24.2 24.2 24.6 21.8
23.6 23.6 23.6 23.6
23.9 22.4
22.8 22.8
22.8 22.8
23.0 22.7
4900
24
21.9 21.6
23.4 16.1 24.3 10.8
20.5
20.5
22.7 15.9 24.0 10.6
19.3 19.3 21.4 15.4
23.4 10.4
17.9 17.9
19.7 15.1
22.5 10.0
27
23.1 23.1
23.6 20.2 24.6 14.4
22.4
22.4
22.9 20.6 24.2 14.6
21.3 21.3 21.8 20.4
23.6 14.8
20.0 20.0
20.2 19.7
22.5 14.7
30
24.0 24.0
24.0 24.0 24.9 18.1
23.6
23.6
23.6 23.6 24.4 18.6
22.9 22.9 22.9 22.9
23.8 19.1
22.0 22.0
22.0 22.0
22.8 19.4
33
24.8 24.8
24.8 24.8 25.2 21.7
24.5
24.5
24.5 24.5 24.8 22.4
24.0 24.0 24.0 24.0
24.2 23.2
23.3 23.3
23.3 23.3
23.3 23.3
Notes:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling, subtract indoor fan heat.
2. TGC = Total Gross Capacity
3. SHC = Sensible Heat Capacity
Table PD-2a — Gross Cooling Capacities (MBH) WSC072AD,T (IP)
Enter.
Ambient Temperature (F)
Dry
85
95
105
115
Bulb
Entering Wet Bulb Temperature (F)
CFM
Temp
61
67
73
61
67
73
61
67
73
61
67
73
Airflow
(F)
TGC SHC
TGC SHC TGC SHC
TGC
SHC
TGC SHC TGC SHC
TGC SHC TGC SHC
TGC SHC
TGC SHC
TGC SHC
TGC SHC
2160
75
70.1 61.0
78.5 46.7 82.3 30.5
65.0
58.4
75.5 45.1 81.3 29.5
59.6 55.8 70.0 43.2
79.0 28.3
53.9 53.1
63.6 40.5
75.2 26.9
80
72.0 72.0
78.8 57.5 83.2 41.7
68.0
68.0
75.7 56.9 81.8 41.4
63.6 63.6 70.3 54.6
79.4 40.1
58.9 58.9
64.0 51.9
75.3 38.7
85
76.7 76.7
79.5 68.6 84.1 51.1
73.5
73.5
76.4 68.7 82.4 51.6
69.3 69.3 71.4 66.6
79.6 51.3
64.6 64.6
65.5 64.0
75.4 50.3
90
80.2 80.2
80.6 79.2 84.9 60.6
78.1
78.1
78.1 78.1 82.9 61.4
74.8 74.8 74.8 74.8
80.1 62.2
70.3 70.3
70.3 70.3
75.8 61.9
2400
75
72.0 64.9
79.4 48.9 82.8 31.0
66.8
62.4
76.7 47.2 81.8 30.0
61.4 59.8 71.5 45.0
79.7 28.8
55.7 55.7
65.0 43.0
76.2 27.5
80
75.0 75.0
79.8 59.9 83.7 42.4
71.1
71.1
77.0 60.1 82.6 42.5
66.5 66.5 71.9 58.1
80.1 41.8
61.6 61.6
65.6 55.4
76.3 40.4
85
78.9 78.9
80.6 71.7 84.6 52.2
76.5
76.5
77.9 72.6 83.4 53.4
72.4 72.4 73.3 71.4
80.5 53.5
67.6 67.6
67.6 67.6
76.5 53.2
90
81.9 81.9
81.8 81.8 85.5 62.3
80.2
80.2
80.2 80.2 84.2 64.5
77.5 77.5 77.4 77.4
81.2 65.2
73.5 73.5
73.5 73.5
77.1 65.5
2640
75
73.5 68.6
79.9 49.2 83.2 31.4
68.6
66.3
77.6 49.1 82.2 30.5
62.9 62.9 72.7 47.9
80.2 29.3
57.9 57.9
66.2 45.3
76.8 27.9
80
77.0 77.0
80.6 62.0 84.1 43.0
73.6
73.6
78.0 62.8 83.1 43.3
69.1 69.1 73.3 61.4
80.7 43.6
64.0 64.0
67.1 58.9
77.1 42.0
85
80.4 80.4
81.5 74.3 85.1 53.3
78.4
78.4
79.2 76.2 84.0 54.9
75.2 75.2 75.1 75.1
81.2 55.4
70.3 70.3
70.3 70.3
77.3 55.6
90
83.0 83.0
83.0 83.0 86.0 63.8
81.8
81.8
81.8 81.8 84.9 66.5
79.4 79.4 79.4 79.4
82.0 67.8
76.0 76.0
76.0 76.0
78.2 68.9
2880
75
75.0 72.4
80.5 50.4 83.5 31.9
70.2
70.2
78.2 51.7 82.5 31.0
65.0 65.0 73.7 50.2
80.6 29.8
59.8 59.8
67.2 47.7
77.4 28.4
80
78.5 78.5
81.2 63.8 84.5 43.5
75.9
75.9
78.9 65.4 83.5 44.1
71.4 71.4 74.6 64.9
81.2 44.2
66.2 66.2
68.4 62.3
77.7 43.6
85
81.5 81.5
82.2 76.7 85.4 54.3
79.9
79.9
80.3 79.3 84.4 56.2
77.1 77.1 77.1 77.1
81.8 57.2
72.5 72.5
72.5 72.5
78.1 57.9
90
83.9 83.9
83.9 83.9 86.4 65.2
82.9
82.9
82.9 82.9 85.4 68.3
80.8 80.8 80.8 80.8
82.7 70.2
77.6 77.6
77.6 77.6
79.1 71.9
Notes:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling, subtract indoor fan heat.
2. TGC = Total Gross Capacity
3. SHC = Sensible Heat Capacity
