Performance
Data
Table PD-16 — Belt Drive Evaporator Fan Performance WSC0120AD,T Horizontal Configuration (SI)
External Static Pressure (Pascals)
25 50 75 100 125 150 175 200 225 250
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
2.24 Nom kW Standard Motor & Low Static Drive 2.24 Nom kW Standard Motor & Drive
5440 — — 691 0.67 730 0.75 771 0.84 807 0.94 844 1.04 886 1.16 926 1.28 965 1.41 1000 1.53
6120 729 0.84 761 0.91 792 0.99 829 1.08 865 1.19 898 1.30 930 1.41 965 1.53 1002 1.67 1038 1.81
6800 802 1.13 833 1.22 860 1.29 890 1.38 923 1.50 956 1.62 986 1.72 1015 1.85 1044 1.98 1077 2.12
7480 876 1.49 905 1.58 931 1.67 955 1.75 983 1.86 1014 1.99 1045 2.12 1072 2.25 1098 2.37 1125 2.51
8160 950 1.91 977 2.02 1002 2.11 1025 2.20 1048 2.30 1074 2.42 1102 2.56 1131 2.71 1156 2.84 1181 2.98
2.24 Nom kW Standard Motor & High Static Drive
Factory Supplied Motors, In Commercial Equipment, Are Definite
Purpose Motors, Specifically Designed And Tested To Operate Reliably
And Continuously At All Cataloged Conditions. Using The Full
Horsepower Range Of Our Fan Motors As Shown In Our Tabular Data
Will Not Result In Nuisance Tripping Or Premature Motor Failure. Our
Product’s Warranty Will Not Be Affected.
External Static Pressure (Pascals)
275 300 325 350 375 400 425 450 475 500
m 3 /h RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
2.24 Nom kW Standard Motor & Drive
5440 1029 1.64 1057 1.75 1084 1.86 1108 1.96 1132 2.06 1155 2.17 1177 2.27 1198 2.37 1219 2.48 1239 3.46
6120 1072 1.95 1106 2.10 1134 2.22 1160 2.35 1185 2.47 1209 2.59 1231 2.70 1252 2.82 1274 2.94 1295 4.10
6800 1111 2.28 1143 2.43 1174 2.58 1204 2.74 1232 2.90 1260 3.05 1283 3.18 1306 3.32 — — — —
7480 1152 2.65 1182 2.81 1211 2.97 1241 3.14 1270 3.31 — — — — — — — — — —
8160 1205 3.12 1229 3.27 — — — — — — — — — — — — — — — —
2.24 Nom kW Standard Motor & High Static Drive
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
2.24 kW - Fan Motor Heat (kW) = 1.138 x Fan kW + 0.139
Table PD-16a — Belt Drive Evaporator Fan Performance WSC0120AD,T Horizontal Configuration (IP)
External Static Pressure (Inches of Water)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Low Static Drive 3 HP Standard Motor & Drive
3200 — — 691 0.89 730 1.00 771 1.13 807 1.26 844 1.39 886 1.55 926 1.72 965 1.89 1000 2.06
3600 729 1.13 761 1.22 792 1.32 829 1.45 865 1.60 898 1.74 930 1.89 965 2.06 1002 2.24 1038 2.43
4000 802 1.52 833 1.63 860 1.73 890 1.86 923 2.01 956 2.17 986 2.30 1015 2.48 1044 2.65 1077 2.85
4400 876 1.99 905 2.12 931 2.24 955 2.35 983 2.49 1014 2.66 1045 2.84 1072 3.01 1098 3.18 1125 3.36
4800 950 2.56 977 2.70 1002 2.84 1025 2.96 1048 3.08 1074 3.24 1102 3.43 1131 3.63 1156 3.81 1181 4.00
3 HP Standard Motor & High Static Drive
Factory Supplied Motors, In Commercial Equipment, Are Definite
Purpose Motors, Specifically Designed And Tested To Operate Reliably
And Continuously At All Cataloged Conditions. Using The Full
Horsepower Range Of Our Fan Motors As Shown In Our Tabular Data
Will Not Result In Nuisance Tripping Or Premature Motor Failure. Our
Product’s Warranty Will Not Be Affected.
External Static Pressure (Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Std Motor & Drive
3200 1029 2.20 1057 2.35 1084 2.49 1108 2.63 1132 2.77 1155 2.91 1177 3.05 1198 3.18 1219 3.32 1239 3.46
3600 1072 2.62 1106 2.81 1134 2.98 1160 3.15 1185 3.31 1209 3.47 1231 3.63 1252 3.78 1274 3.94 1295 4.10
4000 1111 3.05 1143 3.26 1174 3.47 1204 3.68 1232 3.88 1260 4.09 1283 4.27 1306 4.46 — — — —
4400 1152 3.55 1182 3.76 1211 3.99 1241 4.21 1270 4.44 — — — — — — — — — —
4800 1205 4.19 1229 4.39 — — — — — — — — — — — — — — — —
3 HP Standard Motor & High Static Drive
Notes:
Data Includes Pressure Drop Due To Wet Coils And Filters.
3 HP - Fan Motor Heat (MBH) = 2.900 x Fan BHP + 0.475
