Electrical data – Trane WSC060-120 User Manual
Page 37
PKGP-PRC004-EN
37
Table ED-5 — Electrical Characteristics – Compressor Motor And Condenser Motor – 50 Hz
Compressor Motor
Condenser Fan Motor
Unit
Amps
Amps
Model No.
No.
Volts
Phase
HP
1
RPM
RLA
1
LRA
1
No.
Phase
HP
FLA
LRA
WSC060AD
1
380-415
3
6
2875
10.9
74.00
1
1
0.40
1.9
2.8
WSC072AD
1
380-415
3
6.8
2875
11.7
101.00
1
1
0.75
2.8
7.1
WSC090AD
1
380-415
3
8.3
2875
13.2
100.00
1
1
0.75
2.8
7.1
WSC120AD
2
380-415
3
5.7 / 5.7
2875
9.4 / 9.4
74 / 74
1
1
0.75
2.8
7.1
Note:
1. Comp1 / Comp2
Electrical
Data
Table ED-4 — Electrical Characteristics – Evaporator Fan Motor – 50 Hz
Standard Evaporator Fan Motor
Oversized Evaporator Fan Motor
Unit
Amps
Amps
Model No.
No.
Volts
Phase
HP
FLA
LRA
No.
Volts
Phase
HP
FLA
LRA
WSC060AD
1
380-415
3
1.5
4.3
25.3
—
—
—
—
—
—
WSC060AT
1
200
3
1.5
8.1
48.0
—
—
—
—
—
—
WSC072AD
1
380-415
3
1.5
4.3
25.3
1
380-415
3
2.0
5.3
36.4
WSC072AT
1
200
3
1.5
8.1
48.0
1
200
3
2.0
10.8
69.0
WSC090AD
1
380-415
3
2.0
5.3
36.4
1
380-415
3
3.0
7.0
57.0
WSC090AT
1
200
3
2.0
10.8
69.0
1
200
3
3.0
13.4
108
WSC120AD
1
380-415
3
3.0
7.0
57.0
—
—
—
—
—
—
WSC120AT
1
200
3
3.0
13.4
108
—
—
—
—
—
—
