5. DISPLAY
EO1-11138
5-2
5.1 Operator Display
■
Description of each Display Item
(continued)
Display Item
Display Line
Description
9
Printer Error Indicator
15
Displays the error indicator “X” to indicate that an error status has
occurred on the printer which is connected to the terminal. From
the left; Port 1, Port 2 and Port 3. The rightmost one will be used
for the future.
0
Print Data Reception
15
Displays the indicator “
★
” while the print data is being received
Indicator
from another terminal.
A
Sales Item Name
11
Displays a sales item which has been just entered with a double-
Guidance Message
width sized character. (16 double-width sized characters) Also,
displays an operation guidance message. (Max. 36 characters)
B
Quantity
12
Displays a quantity with a double-width sized numeral.
(max. 3-digit integral portion and 2-digit decimal portion)
C
Numeric
12
Displays a numeric value entered and a sales total with a double-
Sales Total
width sized numeral.
1
For Future Use
For Future Use (1 digit)
2
Receipt ON/OFF Indicator
Displays OFF while the receipt-issue mode is in “OFF”. (3 digits)
3
RTR (Register-to-Register) Indicator
Displays RTR while the RTR declaration is in ON. (3 digits)
4
Price Level Indicator
Displays the PLU price level currently selected. (2 digits)
•
PRICE 1 (1st PRICE):
P1
•
PRICE 2 (2nd PRICE):
P2
•
PRICE 3 (3rd PRICE):
P3
•
PRICE 4 (4th PRICE):
P4
•
PRICE 5 (5th PRICE):
P5
5
Menu Shift Level Indicator
Displays the PLU menu shift level currently selected. (2 digits)
•
MENU SHIFT 1:
S1
•
MENU SHIFT 2:
S2
•
MENU SHIFT 3:
S3
•
MENU SHIFT 4:
S4
•
MENU SHIFT 5:
S5
6
Caps Lock and Double-width
Displays the following during the programming operation
Designation
including the character entries. (2 digits)
Small Letter/Normal Size:
a
Capital Letter/Normal Size:
A
Small Letter/Double-width Size:
a
Capital Letter/Double-width Size:
A
5.1.2
Description of each Indicator
••••
*•••• ••••*•••• ••••*•••• ••••*••••
1 1
2 2
10
20
30
40
1| || |||||||78
2 3 4 5 6
■
Description of each Display Item
Display Item
Description
