6. Relight the main burner in both the HI and LO posi-
tions, and verify proper burner ignition and opera-
tion.
7. Check inlet and manifold pressures. Loosen screw
in test port 1/2 turn to measure pressure. Tighten
screw when measurement is complete.
Pressure ranges are:
Gas Supply Pressure (inches w.c.)
Minimum Normal Maximum
LP (Propane) 10.8 11.0 14.0
Manifold Pressure (inches w.c.)
Normal (Hi) Normal (Low)
LP (Propane) 10.0” 6.3”
Manifold pressure can be measured by using a 5/16”
I.D. hose in the right hand side of the valve and con-
necting a manometer. Two test gauge ports are acces-
sible for test gauge connection:
1. Tap on the left side of the valve will give inlet supply
pressure.
2. Tap on the right side of the valve will give manifold
pressure.
Min. Input Max. Input
DV5200MBP 17,500 25,000
