Olympus C-2100 - Manual (Page 34)

34
LOADING THE BATTERIES (Cont.)
5 Insert the batteries.
●
When using AA batteries
Insert the batteries with their poles
oriented in the direction shown in
the illustration.
●
When using lithium battery
packs
Insert the batteries in the direction
shown in the illustration. Do not
insert them in any other direction.
6 Close the battery compartment
cover, then press it down and
slide it in the opposite direction of
the arrow printed on it.
●
When pressing the battery
compartment cover shut, be sure to
press the center of the cover, as it
may be difficult to close properly by
pressing the edge.
●
Make sure the cover is completely
closed.
7 Slide the battery compartment
lock on the battery compartment
cover in the direction of
.
When using lithium battery packs
5
When using AA batteries
6
7
